4
Names of Parts
This air conditioner consists of an indoor unit
and an outdoor unit. You can control the
air conditioner with the remote control unit.
Air Intake Air from the room is drawn into this
section and passes through air filters
which remove dust.
conditioner through the air outlet.
Air Outlet
Conditioned air is blown out of the air
Remote
Control
Unit
The wireless remote control unit
controls power ON/OFF, operation
mode selection, temperature, fan speed,
timer setting, and air sweeping.
Refrigerant
Tubes
The indoor and outdoor units are
connected by copper tubes through
which refrigerant gas flows.
drains off through this hose.
Drain Hose
Moisture in the room condenses and
Outdoor
(Condensing)
Unit
The outdoor unit contains the com-
pressor, fan motor, heat exchanger coil,
and other electrical components.
This illustration is based on the external view
of a standard model.Consequently, the shape
may differ from that of the air conditioner
which you have selected.
NOTE
INDOOR UNIT
Air intakes
Remote control
unit
Air outlet
Refrigerant tubes
Drain hose
OUTDOOR UNIT
Air
outlet
Unit Display and Operation Button
OPERATION
TIMER
ON/OFF
INDOOR UNIT
REMOTE CONTROL
receiver
OPERATION lamp
TIMER lamp
OPERATION
button
(ON/OFF)
REMOTE
CONTROL
receiver
This section picks up infrared signals
from the remote control unit
(transmitter).
OPERATION
lamp
TIMER
lamp
This lamp lights when the system is
Avoid using radio equipment such as mobile phone
near (within 1 m) the remote control receiver.
Some radio equipment may cause malfunction
of the unit.
If the trouble happens, disconnect power and restart
the air conditioner after a few minutes.
IMPORTANT
This lamp lights when the system is
in the continuous DRY, COOL, HEAT
and FAN mode.
being controlled by the timer.
OPERATION
button
When the remote control cannot be
used, pressing this button enables
heating and cooling operation.
Each time this button is pressed,
the operation mode changes cyclically.
The type of operation is indicated
by the OPERATION lamp lighting
and the beeping sound.
COOLING
OPERATION
lamp
on on off
twiceonce once
beeping
sound
HEATING
OPERATION
STOP
