1. Specifications
1
2
3
4
– 8 –
SM830076
1-1 Unit Specifications
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height in. (mm) 9-27/32 (250) 28-30/32 (735)
Width in. (mm) 29-29/32 (760) 37 (940)
Depth in. (mm) 29-29/32 (760) 13-12/32 (340)
Net weight lbs. (kg) 49 (22) 157 (71)
Indoor grille dimensions Height in. (mm) 3-1/16 (78)
PNR-XHS2432 Width in. (mm) 33-27/32 (860)
Depth in. (mm) 33-27/32 (860)
Net weight lbs. (kg) 11 (5)
Indoor / Outdoor unit Height in. (mm) 11-6/32 (284) 32-17/32 (826)
Package dimensions Width in. (mm) 32-14/32 (824) 40 (1,016)
Depth in. (mm) 32-25/32 (833) 16-12/32 (416)
Shipping weight lbs. (kg) 60 (27) 170 (77)
Shipping volume cu.ft. (m
3
) 6.9 (0.195) 12.3 (0.349)
Indoor grille Height in. (mm) 4-3/32 (104)
Package dimensions Width in. (mm) 38-2/32 (967)
PNR-XHS2432 Depth in. (mm) 39-11/32 (999)
Shipping weight lbs. (kg) 18 (8)
Shipping volume cu.ft. (m
3
) 3.5 (0.100)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions (*) : Room temperature 80 °F DB / 67 °F WB, Ambient temperature 95 °F DB / 75 °F WB
Heating :
Rating conditions (*) : Room temperature 70 °F DB / 60 °F WB, Ambient temperature 47 °F DB / 43 °F WB
Low temp conditions (**) : Room temperature 70 °F DB / 60 °F WB, Ambient temperature 17 °F DB / 15 °F WB
