Data Output Format
You can output the values displayed in the line for measured
values and the weight unit with or without a data ID code.
The first 6 characters, called the data header, show the data ID code
identifying the subsequent value. Select menu item 7.2 to define
whether the data ID code is included in output or not.
Examples:
+ 235 pcs Without data ID code
Qnt + 235 pcs With data ID code
Display segments that are not activated are output as spaces.
Values with no decimal point are output without a decimal point.
Data Output Format with 16 Characters (without Data Header)
Normal Operation
Position 12345678910111213141516
+* DDDDDDDD * UUUCRLF
or - * DDDDDDDD * UUUCRLF
or **************CRLF
+-: Plus or minus sign
*: Space
D: Digit or letter (max. 7 characters plus decimal point)
U: Unit symbol (1 - 3 letters, followed by 0 - 2 spaces)
CR: Carriage return
LF: Line feed
Special Codes
Position 12345678910111213141516
******––******CRLF
or ******H*******CRLF
or ******HH******CRLF
or ******L*******CRLF
or ******LL******CRLF
or ******C*******CRLF
*: Space
– –: Final readout mode
H: Overload
HH: Overload in Checkweighing
L: Underload
LL: Underload in Checkweighing
C: Calibration/adjustment
97
Error Codes
Position 12345678910111213141516
***Err**##****CRLF
or ***Err*###****CRLF
*: Space
#: Error code number (2 or 3 digits)
Example (output of value: +1255.7 g):
Position 12345678910111213141516
+* * * 1255. 7 * g * * CRLF
Position 1: Plus or minus sign or space
Position 2: Space
Positions 3-10: Weight value with decimal point;
leading zeros are output as spaces.
Position 11: Space
Positions 12-14: Unit symbol or space
Position 15: Carriage return
Position 16: Line feed
Data Output Format with 22 Characters
Normal Operation
Position 12345678910111213141516171819202122
IIIIII+*DDDDDDDD* UUUCRLF
or IIIIII-*DDDDDDDD* UUUCRLF
or ********** **********CRLF
II: ID code character, right-justified with spaces
+-: Plus or minus sign
*: Space
D: Digit or letter (max. 7 characters plus decimal point)
U: Unit symbol (1 - 3 letters, followed by 0 - 2 spaces)
CR: Carriage return
LF: Line feed
Special Codes
Position 12345678910111213141516171819202122
Stat****** * * ––* *****CRLF
or Stat****** * * H*******CRLF
or Stat****** * * HH* *****CRLF
or Stat****** * * L* * *****CRLF
or Stat****** * * LL* *****CRLF
or Stat****** * * C* * *****CRLF
**: Space – –: Final readout mode
H: Overload HH: Overload in Checkweighing
L: Underload LL: Underload in Checkweighing
C: Calibration/adjustment
