SATO CL6NX User Manual

3
About This Manual
Thank you for using the SATO PDF Direct Print.
This document is intended for users who want to know how to configure SATO printers with PDF
Direct Print function or system integrators who want to develop a solution that can send PDF data from
their system and directly print the PDF data without graphics conversion on SATO printers with PDF
Direct Print function.
This document describes only the information and instructions related to PDF Direct Print. For more
details on other printer operations and settings, please refer to each printer's operator manual.
Click the link below for the CL4NX/CL6NX operator manual.
http://www.manual.sato-global.com/printer/cl4nx_cl6nx/main/index.html
Click the link below for the CL4NX Plus operator manual.
http://www.manual.sato-global.com/printer/clnxplus/main/index.html

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
