m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, lm and small parts! There is a risk of
swallowing and suffocation!
9. Attachment / Before starting the
equipment
9.1 Fitting the wheels (7) (accessories bag A)
• Insert the bolt through the wheel.
• Attach two washers.
• Now insert the bolt through the holes in the lower
•
•
• Repeat this process on the other side.
9.2 Fitting the table (5)
• Undo the star-grip screw (Fig. 4)
• Now fold out both side trays (11), as shown in Fig. 5
•
(1) and re-tighten the star grip screws previously
loosened (Fig. 6 (2).
9.3 Fitting the complete control arms (10)
(accessories bag B)
•
• Grease the top and bottom plates.
• Insert the complete control arm in the position
• Guide control arm (A) into the rocker switch (B) (Fig.
7 (2)
• Secure the control arms completely with the bolts
• Now fasten the other control arm on the other side
in accordance with the method described
9.4 Fitting the claws (enclosed accessories bag C)
• Fasten the additional retainers (D) to the claws with
two Phillips head screws, washers and nuts (Fig. 8)
• Make sure that the larger additional retainer is
fastened with the left claw (4).
• Place the adjustable claws on the hexagon nuts
previously attached, and fasten these with the star
grip screws and washers enclosed (Fig. 8)
• Note that the prongs on the claws must point
m IMPORTANT!
You must fully assemble the appliance before using it
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Release the handle button and switch off the ma-
chine prior to any operations.
• Avoid accidental starts of the machine: Do not
press the start button while inserting the plug into
the socket.
• Use the tools recommended in this manual to ob-
tain the best results from your machine.
• Always keep hands away from the work area when
the machine is running.
7. Technical data
Motor V/Hz
400V / 50Hz
Input P1 W
3500
Output P2 W
2500
Operating mode
S6 40%
Motor speed 1/min
2800
Phase inverter
yes
Dimensions D/W/H
845 x 935 x 1500
Table height
800 mm
Working height
940 mm
Log length
550 mm
Power max. tons*
8
Piston stroke
550 mm
Forward speed
6 cm/s
Return speed
19,4 cm/s
Oil quantity
4 l
Weight
109 kg
Subject to technical changes!
8. Unpacking
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available).
Check that the delivery is complete.
Check the device and accessory parts for transport
damage.
In case of complaints the dealer must be informed
immediately. Subsequent complaints will not be ac-
cepted.
If possible, store the packaging until the warranty pe-
riod has expired.
Read the operating manual to make yourself familiar
with the device prior to using it.
Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
Specify our part numbers as well as the type and year
of construction of the device in your orders.
