Sharp 14BM2G User Manual

41
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
14BM2, 14BM2S/G
20BM2, 20BM2S/G
21BM2, 21BM2S/G
Ref. No. Part No. ★ Description Code
PICTURE TUBE
å VB37GDA86X/1E R Picture Tube (14BM2S/G) CB
å VB510CKAY1S3E R Picture Tube (20BM2S/G) CA
å VB51JSY63X/*S R Picture Tube (21BM2S/G) CE
å L708 RCiLG0068PEZZ R Degaussing Coil AH
(14BM2G)
å L708 RCiLG0095PEZZ R Degaussing Coil AH
(14BM2S/G(Y))
å L708 RCiLG0074PEZZ R Degaussing Coil AQ
(20BM2S/G)
å L708 RCiLG0069PEZZ R Degaussing Coil AR
(21BM2S/G)
RCiLH0149PEZZ R Deflection Yoke BA
(14BM2S/G)
RCiLH0146PEZZ R Deflection Yoke BF
(21BM2S/G)
PMAGF3045CEZZ R Magnet(14BM2S/G) AG
PMAGF3046CEZZ R Magnet(21BM2S/G) AF
QEARC1422PEZZ R Grounding Strap AD
(14BM2S/G)
QEARC2017PEZZ R Grounding Strap AE
(20BM2S/G)
QEARC2107PEZZ R Grounding Strap AE
(21BM2S/G)
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTK9988WEV6 - Main Unit(14BM2S/G(Y))—
PWB-A DUNTK9988WEV7 - Main Unit(14BM2G) —
PWB-A DUNTK9988WEW0 - Main Unit(20BM2S) —
PWB-A DUNTK9988WEW1 - Main Unit(20BM2G) —
PWB-A DUNTK9988WEW4 - Main Unit(21BM2S/G) —
PWB-B DUNTK9990WEV0 - CRT Unit(14BM2S/G(Y))—
PWB-B DUNTK9990WEV3 - CRT Unit(14BM2G) —
PWB-B DUNTK9990WEV6 - CRT Unit(20BM2S) —
PWB-B DUNTK9990WEV7 - CRT Unit(20BM2G) —
PWB-B DUNTK9990WEV9 - CRT Unit(21BM2S/G) —
REPLACEMENT PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK ★: SPARE PARTS-DELIVERY SECTION
DUNTK9988WEV6(14BM2S/G(Y))
DUNTK9988WEV7(14BM2G)
DUNTK9988WEW0(20BM2S)
DUNTK9988WEW1(20BM2G)
DUNTK9988WEW4(21BM2S/G)
PWB-A : MAIN UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU201 VTUATEDE9-023 R VHF Tuner(20BM2S/G) BB
å TU201 VTUVTST5HD84/ R VHF Tuner BB
(14BM2S/G/21BM2S/G)
INTEGRATED CIRCUITS
IC301 VHiTDA7056A-1 R TDA7056A AP
IC304 VHiLA7016//-1 R LA7016, Audio SW AH
IC501 VHiTDA8357/-1 R TDA8357 AN
IC402 VHiLA7016//-1 R LA7016, Video SW AH
IC605 VHiKA7808AP-1 R KA7808AP AE
IC701 VHiSTRF6654-1 R STRF6654 AX
(20BM2S/G/21BM2S/G)
IC701 VHiSTRF6653-1 R STRF6653(14BM2S/G) AS
IC751 VHiTA48M033-1 R TA48M033 AH
IC753 VHiSE115N//-1 R SE115N AF
IC801 RH-iX3368CEN3 R IX3368CE BC
IC1002 VHiPST573J/-1 R PST573J, Reset AE
IC1003 VHiM24C04W/-1 R M24C04W AG
IC1005 VHiKA7805AP-1 R KA7805AP AE
TRANSISTORS
Q201 VS2SC2735//1E R 2SC2735 AC
Q203 VS2SD601A//-1 R 2SD601A AC
Q205 VS2SC1815GW-1 R 2SC1815GW AB
Q301 VS2SD601A//-1 R 2SD601A AC
Q302 VS2SD601A//-1 R 2SD601A AC
Q305 VS2SD601A//-1 R 2SD601A AC
Q601 VS2SC2482//-1 R 2SC2482 AD
Q602 VS2SD1877//1E R 2SD1877(14BM2S/G) AL
Q602 VS2SD2586//1E R 2SD2586 AM
(20BM2S/G/21BM2S/G)
Q603 VS2SD601A//-1 R 2SD601A AC
Q723 VS2SD601A//-1 R 2SD601A AC
Q752 VS2SC1815GW-1 R 2SC1815GW AB
Q753 VS2SC1815GW-1 R 2SC1815GW AB
Q801 VS2SB709A//-1 R 2SB709A AA
Q802 VS2SB709A//-1 R 2SB709A AA
Q1003 VS2SD601A//-1 R 2SD601A AC
Q1010 VS2SD601A//-1 R 2SD601A AC
DIODES
D201 RH-EX0676GEZZ R Zener Diode AA
D301 RH-DX0475CEZZ R DX0475CE AB
D305 RH-EX0631GEZZ R Zener Diode AA
D308 RH-EX0631GEZZ R Zener Diode AA
D311 VHDRL3Z////-1 R RL3Z AE
D401 RH-EX0631GEZZ R Zener Diode AA
D402 RH-EX0631GEZZ R Zener Diode AA
D501 RH-EX0640GEZZ R Zener Diode AA
D502 RH-DX0475CEZZ R DX0475CE AB
D503 RH-DX0475CEZZ R DX0475CE AB
D504 RH-DX0475CEZZ R DX0475CE AB
D505 RH-DX0127CEZZ R DX0127CE AC
D507 RH-DX0475CEZZ R DX0475CE AB
D508 RH-EX0647GEZZ R Zener Diode AA
D509 RH-EX0647GEZZ R Zener Diode AA
D510 RH-EX0867CEZZ R Zener Diode AC
D511 RH-EX0867CEZZ R Zener Diode AC
D512 RH-DX0475CEZZ R DX0475CE AB
D513 RH-DX0475CEZZ R DX0475CE AB
D514 RH-EX0903CEZZ R Zener Diode AC
D515 RH-EX0903CEZZ R Zener Diode AC
D602 RH-DX0475CEZZ R DX0475CE AB
D603 RH-DX0131CEZZ R DX0131CE AC
