Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
14BM2, 14BM2S/G
20BM2, 20BM2S/G
21BM2, 21BM2S/G
BALUNES
FB306 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB501 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB502 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB602 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB701 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB702 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB751 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB752 RBLN-0037CEZZ R Balun, BLN-0037CE AB
SWITCHES
å S701 QSW-P0591CEZZ R Switch AQ
S1001 QSW-K0077GEZZ R Switch, CH Up AB
S1002 QSW-K0077GEZZ R Switch, CH Down AB
S1003 QSW-K0077GEZZ R Switch, VOL Up AB
S1004 QSW-K0077GEZZ R Switch, VOL Down AB
S1005 QSW-K0077GEZZ R Switch, Picture/Preset AB
MISCELLANEOUS PARTS
RDA754 PRDAR0224PEFW R Heat Sink, Q602 AF
RDA756 PRDAR0248PEFW R Heat Sink, IC301 AF
RDA701 PRDAR0260PEFW R Heat Sink, IC701 AH
RDA501 PRDAR0298PEFW R Heat Sink, IC501 AF
(20BM2S/G/21BM2S/G)
RDA501 PRDAR0283PEFW R Heat Sink, IC501 AF
(14BM2S/G)
å FH701 QFSHD1014CEZZ R Fuse Holder AC
å FH702 QFSHD1013CEZZ R Fuse Holder AC
å F701 QFS-C3229CEZZ R Fuse, T3.15A 250V AD
J402 QJAKE0205CE04 R Jack, 3Pin AD
J403 QJAKE0205CE09 R Jack, 3Pin AD
J405 QJAKH0011AJZZ R Jack, 18Pin AK
P301 QPLGN0441CEZZ R Plug, 4Pin AB
P502 QPLGN0660CEZZ R Plug, 6Pin AC
P602 QPLGN0641CEZZ R Plug, 6Pin AB
P701 QPLGN0260CEZZ R Plug, 2Pin AC
P712 QPLGN0269GEZZ R Plug, 2Pin AB
P1001 QPLGN0541CEZZ R Plug, 5Pin AB
P1002 QPLGN0541CEZZ R Plug, 5Pin AB
RMC1001 RRMCU0235CEZZ R Remote Receiver AK
TP201 QLUGP0102PEZZ R Lug AA
LHLDP1066PE00 R Holder AC
DUNTK9990WEV0(14BM2S/G(Y))
DUNTK9990WEV3(14BM2G)
DUNTK9990WEV6(20BM2S)
DUNTK9990WEV7(20BM2G)
DUNTK9990WEV9(21BM2S/G)
CRT UNIT
TRANSISTORS
Q870 VSBF422////-1 R BF422 AC
Q871 VSBF422////-1 R BF422 AC
Q872 VSBF422////-1 R BF422 AC
Q883 VSBF421////-1 R BF421 AC
Q885 VSBF421////-1 R BF421 AC
Q887 VSBF421////-1 R BF421 AC
DIODES
D811 RH-DX0475CEZZ R DX0475CE AB
D812 RH-DX0475CEZZ R DX0475CE AB
D880 RH-DX0475CEZZ R DX0475CE AB
D881 RH-DX0475CEZZ R DX0475CE AB
D882 RH-DX0475CEZZ R DX0475CE AB
D883 VHD1SS82///1A R 1SS82 AC
D884 VHD1SS82///1A R 1SS82 AC
D885 VHD1SS82///1A R 1SS82 AC
D886 VHD1SS82///1A R 1SS82 AC
D887 VHD1SS82///1A R 1SS82 AC
D888 VHD1SS82///1A R 1SS82 AC
D890 RH-EX0627GEZZ R Zener Diode AA
(20BM2S/G/21BM2S/G)
R709 VRD-RA2BE681J R 680 1/8W Carbon AA
R710 VRN-VV3ABR39J R 0.39 1W Metal Film AA
R711 VRN-VV3ABR33J R 0.33 1W Metal Film AA
å R712 VRG-PD2HD150J R 15 1/2W AC
(20BM2S/G/21BM2S/G)
å R712 VRG-PD2HD4R7J R 4.7 1/2W (14BM2S/G) AC
R717 VRD-RM2HD124J R 120k 1/2W Carbon AA
R718 VRD-RM2HD124J R 120k 1/2W Carbon AA
å R719 VRC-UA2HG825K R 8.2M 1/2W Solid AA
R721 VRD-RA2BE393J R 39k 1/8W Carbon AA
R722 VRD-RM2HD124J R 120k 1/2W Carbon AA
R723 VRD-RA2BE684J R 680k 1/8W Carbon AA
å R726 VRC-UA2HG825K R 8.2M 1/2W Solid AA
R728 VRN-MD2AL272J R 2.7k 0.1W Metal Film AA
R750 VRD-RM2HD4R7J R 4.7 1/2W Carbon AA
R755 VRD-RA2BE222J R 2.2k 1/8W Carbon AA
R756 VRN-MD2AL152J R 1.5k 0.1W Metal Film AA
R758 VRD-RA2BE102J R 1k 1/8W Carbon AA
R759 VRN-MD2AL102J R 1k 0.1W Metal Film AA
R760 VRD-RA2BE471J R 470 1/8W Carbon AA
R761 VRD-RA2BE221J R 220 1/8W Carbon AA
R764 VRN-MD2AL272J R 2.7k 0.1W Metal Film AA
R766 VRD-RM2HD680J R 68 1/2W Carbon AA
R801 VRN-MD2AL101J R 100 0.1W Metal Film AA
R802 VRN-MD2AL101J R 100 0.1W Metal Film AA
R803 VRN-MD2AL101J R 100 0.1W Metal Film AA
R804 VRN-MD2AL101J R 100 0.1W Metal Film AA
R805 VRN-MD2AL822J R 8.2k 0.1W Metal Film AA
R806 VRD-RA2BE123J R 12k 1/8W Carbon AA
R807 VRN-MD2AL103J R 10k 0.1W Metal Film AA
R808 VRN-MD2AL221J R 220 0.1W Metal Film AA
R809 VRD-RA2BE224J R 220k 1/8W Carbon AA
R811 VRN-MD2AL563J R 56k 0.1W Metal Film AA
(20BM2S/G/21BM2S/G)
R812 VRN-MD2AL101J R 100 0.1W Metal Film AA
R813 VRN-MD2AL221J R 220 0.1W Metal Film AA
R1001 VRD-RA2BE221J R 220 1/8W Carbon AA
R1002 VRN-MD2AL331J R 330 0.1W Metal Film AA
R1003 VRN-MD2AL471J R 470 0.1W Metal Film AA
R1004 VRN-MD2AL821J R 820 0.1W Metal Film AA
R1005 VRD-RA2BE181J R 180 1/8W Carbon AA
R1011 VRN-MD2AL820J R 82 0.1W Metal Film AA
R1012 VRN-MD2AL391J R 390 0.1W Metal Film AA
R1013 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1014 VRD-RA2BE101J R 100 1/8W Carbon AB
R1015 VRN-MD2AL332J R 3.3k 0.1W Metal Film AA
R1016 VRD-RA2BE101J R 100 1/8W Carbon AB
R1017 VRN-MD2AL332J R 3.3k 0.1W Metal Film AA
R1019 VRN-MD2AL472J R 4.7k 0.1W Metal Film AA
R1020 VRD-RA2BE101J R 100 1/8W Carbon AB
R1021 VRN-MD2AL153J R 15k 0.1W Metal Film AA
R1022 VRD-RA2BE101J R 100 1/8W Carbon AB
R1023 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1024 VRN-MD2AL122J R 1.2k 0.1W Metal Film AA
R1025 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1026 VRN-MD2AL224J R 220k 0.1W Metal Film AA
R1027 VRD-RA2BE101J R 100 1/8W Carbon AB
R1028 VRD-RA2BE101J R 100 1/8W Carbon AB
R1030 VRN-MD2AL102J R 1k 0.1W Metal Film AA
R1031 VRD-RA2BE562J R 5.6k 1/8W Carbon AA
R1032 VRN-MD2AL332J R 3.3k 0.1W Metal Film AA
R1033 VRD-RA2BE102J R 1k 1/8W Carbon AA
R1034 VRD-RA2BE101J R 100 1/8W Carbon AB
R1035 VRN-MD2AL332J R 3.3k 0.1W Metal Film AA
R1036 VRN-MD2AL332J R 3.3k 0.1W Metal Film AA
R1037 VRD-RA2BE101J R 100 1/8W Carbon AB
R1038 VRD-RA2BE101J R 100 1/8W Carbon AB
R1039 VRN-MD2AL223J R 22k 0.1W Metal Film AA
R1040 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1041 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1043 VRN-MD2AL153J R 15k 0.1W Metal Film AA
R1044 VRN-MD2AL153J R 15k 0.1W Metal Film AA
R1045 VRD-RA2BE271J R 270 1/8W Carbon AA
R1046 VRD-RA2BE101J R 100 1/8W Carbon AB
R1065 VRN-MD2AL101J R 100 0.1W Metal Film AA
R1067 VRN-MD2AL000J R 0 0.1W Metal Film AA
