46
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
14BM2, 14BM2S/G
20BM2, 20BM2S/G
21BM2, 21BM2S/G
CAPACITORS
C871 VCKYPA1HB471K R 470p 50V Ceramic AA
C872 VCKYPA1HB471K R 470p 50V Ceramic AA
C873 VCKYPA1HB471K R 470p 50V Ceramic AA
C875 VCKYPA2HB102K R 1000p 500V Ceramic AA
C876 RC-KZ0150CEZZ R Capacitor AB
C878 VCEAGA2EW106M R 10 250V Electrolytic AC
(14BM2S/G)
C878 VCEAGA2EW336M R 33 250V Electrolytic AD
(20BM2S/G/21BM2S/G)
C880 VCKYPA1HB471K R 470p 50V Ceramic AA
C881 VCKYPA1HB471K R 470p 50V Ceramic AA
C882 VCKYPA1HB471K R 470p 50V Ceramic AA
RESISTORS
R879 VRD-RA2BE471J R 470 1/8W Carbon AA
R880 VRD-RA2BE471J R 470 1/8W Carbon AA
R881 VRD-RA2BE471J R 470 1/8W Carbon AA
R882 VRS-VU3DE153J R 15k 2W Metal Oxide AB
R883 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R884 VRS-VU3DE153J R 15k 2W Metal Oxide AB
R885 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R886 VRS-VU3DE153J R 15k 2W Metal Oxide AB
R887 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R888 VRD-RA2BE471J R 470 1/8W Carbon AA
(14BM2S/G)
R892 VRD-RA2BE102J R 1k 1/8W Carbon AA
R893 VRD-RA2BE102J R 1k 1/8W Carbon AA
R894 VRD-RA2BE102J R 1k 1/8W Carbon AA
R895 VRD-RA2BE471J R 470 1/8W Carbon AA
(20BM2S/G/21BM2S/G)
R896 VRD-RA2BE471J R 470 1/8W Carbon AA
(20BM2S/G/21BM2S/G)
R898 VRD-RA2BE471J R 470 1/8W Carbon AA
(14BM2S/G)
R899 VRD-RA2BE471J R 470 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0641CEZZ R Plug AB
(20BM2S/G/21BM2S/G)
P851 QPLGN0661CEZZ R Plug, 6Pin(14BM2S/G) AD
P882 QPLGN0541CEZZ R Plug AB
(20BM2S/G/21BM2S/G)
P882 QPLGN0561CEZZ R Plug, 5Pin(14BM2S/G) AB
å SC882 QSOCV0931CEZZ R Socket AK
MISCELLANEOUS PARTS
QANTR0018PEZZ R Rod Antenna(14BM2S/G) AQ
QACCZ2008PEZZ R AC Cord AM
QCNW-2377PEZZ R Connecting Cord AE
(14BM2S/G)
QCNW-2380PEZZ R Connecting Cord AG
(14BM2S/G)
QCNW-2381PEZZ R Connecting Cord AG
(20BM2S/G/21BM2S/G)
QCNW-2405PEZZ R Connecting Cord AE
(20BM2S/G/21BM2S/G)
QCNW-2423PEN1 R Connecting Cord AF
(14BM2S/G)
QCNW-2433PEN1 R Connecting Cord AF
(20BM2S/G/21BM2S/G)
VSP1206PB50WA R Speaker AP
(20BM2S/G/21BM2S/G)
VSP9050PB25WA R Speaker(14BM2S/G) AM
SUPPLIED ACCESSORIES
ACCESSORIES
RRMCG1342PESA R Infrared R-C AU
TiNS-7170PEZZ R Instruction Book AK
QPLGJ0113CEZZ R Plug(14BM2S/G) AG
ACCESSORY (NOT REPLACEMENT ITEM)
TCAUA0002PEZZ - Caution Card —
PACKING PARTS
(NOT REPLACEMENT ITEM)
SPAKC6436PEZZ - Packing Case(21BM2S) —
SPAKC6437PEZZ - Packing Case(21BM2G) —
SPAKC6687PEZZ - Packing Case(14BM2S) —
SPAKC6688PEZZ - Packing Case(14BM2G/G(Y))—
SPAKC6691PEZZ - Packing Case(20BM2S) —
SPAKC6695PEZZ - Packing Case(20BM2G) —
SPAKX2755PEZZ - Packing Add.(14BM2S/G) —
SPAKX2756PEZZ - Packing Add. —
(20BM2S/G/21BM2S/G)
SSAKA0031PEZZ - Polyethylene Bag —
SSAKH0015PEZZ - Polyethylene Bag —
(14BM2S/G)
SSAKH0016PEZZ - Polyethylene Bag —
(20BM2S/G/21BM2S/G)
CABINET PARTS
14BM2S/G
1 CCABA2621WEV0 R Front Cabinet Ass'y BE
(14BM2S)
1 CCABA2621WEV1 R Front Cabinet Ass'y BE
(14BM2G/G(Y))
1-1 Not Available - Front Cabinet —
1-2 HBDGB0019PESB R SHARP Badge AD
1-3 JBTN-0345PESA R Control Button(14BM2S) AG
1-3 JBTN-0345PESB R Control Button(14BM2G) AH
1-4 HDECQ0186PESA R LED, R/C Cover AD
1-5 JBTN-0346PESA R Power Button(14BM2S) AD
1-5 JBTN-0346PESB R Power Button(14BM2G) AD
1-6 MSPRC0068CEFW R Power Button Spring AA
1-7 HDECQ0184PESA R Right Speaker Net AK
1-8 HDECA0081PESA R Right Speaker Decoration AE
1-9 HDECQ0185PESA R Left Speaker Kit AK
1-10 HDECA0082PESA R Left Speaker Decoration AE
2 CCABB2432WEV0 R Rear Cabinet Ass'y AX
2-1 Not Available - Rear Cabinet —
20BM2S/G
1 CCABA2628WEV0 R Front Cabinet Ass'y BM
(20BM2S)
1 CCABA2628WEV1 R Front Cabinet Ass'y BM
(20BM2G)
1-1 Not Available - Front Cabinet —
1-2 HBDGB0015PESB R SHARP Badge AE
1-3 HDECQ0186PESA R RC/LED Cover AD
1-4 HDECA0083PESA R SP Decoration-R AE
1-5 HDECA0084PESA R SP Decoration-L AE
1-6 HDECQ0187PESA R SP NET-R(20BM2S) AQ
1-6 HDECQ0187PESB R SP NET-R(20BM2G) AQ
1-7 HDECQ0188PESA R SP NET-L(20BM2S) AQ
1-7 HDECQ0188PESB R SP NET-L(20BM2G) AQ
1-8 JBTN-0345PESA R Control Button(20BM2S) AG
1-8 JBTN-0345PESB R Control Button(20BM2G) AH
1-9 JBTN-0347PESA R Power Button(20BM2S) AD
1-9 JBTN-0347PESB R Power Button(20BM2G) AD
