Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
14U10/15
14U20/25
IC1005 VHiKA7805AP-1 R KA7805AP AE
TRANSISTORS
Q201 VS2SC2735//1E R 2SC2735 AC
Q203 VS2SD601A//-1 R 2SD601A AC
Q205 VS2SC1815GW-1 R 2SC1815GW AB
Q301 VS2SD601A//-1 R 2SD601A AC
Q302 VS2SD601A//-1 R 2SD601A AC
Q305 VS2SD601A//-1 R 2SD601A AC
Q601 VS2SC2482//-1 R 2SC2482 AD
Q602 VS2SD1877//1E R 2SD1877 AL
Q603 VS2SD601A//-1 R 2SD601A AC
Q710 VS2SC4517//-1 R 2SC4517 AG
Q711 VS2SD601A//-1 R 2SD601A AC
Q723 VS2SD601A//-1 R 2SD601A AC
Q751 VS2SA1015G/1E R 2SA1015G AC
Q752 VS2SC1815GW-1 R 2SC1815GW AB
Q753 VS2SC1815GW-1 R 2SC1815GW AB
Q801 VS2SB709A//-1 R 2SB709A AA
Q802 VS2SB709A//-1 R 2SB709A AA
Q1003 VS2SD601A//-1 R 2SD601A AC
Q1010 VS2SD601A//-1 R 2SD601A AC
DIODES AND LED’S
D201 RH-EX0676GEZZ R Zener Diode AA
D301 VHD1SS119//-1 R 1SS119 AB
D305 RH-EX0631GEZZ R Zener Diode AA
D308 RH-EX0631GEZZ R Zener Diode(14U20/25) AA
D311 VHDRL3Z////-1 R RL3Z AE
D401 RH-EX0631GEZZ R Zener Diode(14U20/25) AA
D402 RH-EX0631GEZZ R Zener Diode AA
D501 RH-EX0640GEZZ R Zener Diode AA
D502 VHD1SS119//-1 R 1SS119 AB
D503 VHD1SS119//-1 R 1SS119 AB
D504 VHD1SS119//-1 R 1SS119 AB
D505 RH-DX0127CEZZ R DX0127CE AC
D507 VHD1SS119//-1 R 1SS119 AB
D508 RH-EX0647GEZZ R Zener Diode AA
D509 RH-EX0647GEZZ R Zener Diode AA
D510 RH-EX0867CEZZ R Zener Diode AC
D511 RH-EX0867CEZZ R Zener Diode AC
D512 VHD1SS119//-1 R 1SS119 AB
D513 VHD1SS119//-1 R 1SS119 AB
D514 RH-EX0903CEZZ R Zener Diode AC
D515 RH-EX0903CEZZ R Zener Diode AC
D602 VHD1SS119//-1 R 1SS119 AB
D603 RH-DX0062CEZZ R DX0062CE AD
D604 VHD1SS119//-1 R 1SS119 AB
D605 RH-EX0840CEZZ R Zener Diode AC
D606 VHD1SS119//-1 R 1SS119 AB
D607 RH-EX0662GEZZ R Zener Diode AB
D608 RH-EX0604GEZZ R Zener Diode AB
D609 VHD1SS119//-1 R 1SS119 AB
D610 RH-EX0662GEZZ R Zener Diode AB
D611 RH-DX0302CEZZ R DX0302CE AC
D612 RH-EX0627GEZZ R Zener Diode AA
D613 VHD1SS119//-1 R 1SS119 AB
D614 VHD1SS119//-1 R 1SS119 AB
D701 RH-DX0386CEZZ R DX0386CE AG
D702 VHD1SS82///1A R 1SS82 AC
D705 RH-DX0492CEZZ R DX0492CE AE
D706 VHD1SS82///1A R 1SS82 AC
D707 VHD1SS82///1A R 1SS82 AC
D708 RH-DX0400CEZZ R DX0400CE AC
D709 RH-DX0164CEZZ R DX0164CE AC
D710 RH-EX0601GEZZ R Zener Diode AA
D711 VHD1SS82///1A R 1SS82 AC
D712 VHD1SS82///1A R 1SS82 AC
D713 RH-EX0621GEZZ R Zener Diode AB
D714 RH-DX0055TAZZ R DX0055TA AD
D715 RH-DX0055TAZZ R DX0055TA AD
D716 RH-EX0615GEZZ R Zener Diode AA
D718 RH-EX0649GEZZ R Zener Diode AB
D719 RH-EX0649GEZZ R Zener Diode AB
D751 RH-DX0471CEZZ R DX0471CE AE
D752 VHD1SS119//-1 R 1SS119 AB
D753 RH-DX0471CEZZ R DX0471CE AE
REPLACEMENT PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
are identified in this manual; electrical components having such
features are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK : SPARE PARTS-DELIVERY SECTION.
Ref. No. Part No. ★ Description Code
PICTURE TUBE
å V1 VB34KPU02X/1E R Picture Tube CB
å L708 RCiLG0023KMZZ Degaussing Coil
RCiLH0021PEZZ R Deflection Yoke BB
PMAGF3045CEZZ R Magnet AG
LHLDW0003PEKZ R Holder AB
MSPRT0001PEFJ R Spring AC
PSPAG0004PEZZ R Spacer AB
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTK9988WEZ2 - Main Unit(14U10/15) —
PWB-A DUNTK9988WEZ4 - Main Unit(14U20/25) —
PWB-B DUNTK9990WEZ4 - CRT Unit —
PWB-C DUNTK9989WEV1 - Headphone Unit(14U20/25) —
PWB-A DUNTK9988WEZ2/4 MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY NOT INDEPENDENTLY.
å TU201 VTUVTST5HD84/ R Tuner BB
INTEGRATED CIRCUITS
IC301 VHiTDA7056A-1 R TDA7056A AP
IC304 VHiLA7016//-1 R LA7016, Audio SW AH
(14U20/25)
IC402 VHiLA7016//-1 R LA7016, Video SW AH
(14U20/25)
IC501 VHiTDA8357/-1 R TDA8357 AN
IC605 VHiKA7808AP-1 R KA7808AP AE
IC701 VHiSTRF6653-1 R STRF6653 AS
IC751 VHiTA48M033-1 R TA48M033F AH
IC753 VHiSE115N//-1 R SE115N AF
IC801 RH-iX3368CEN1 R IX3368CE BE
IC1002 VHiPST573J/-1 R PST573J, Reset AE
IC1003 VHiM24C04W/-1 R M24C04W AG
