Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
47
14U10/15
14U20/25
R1035 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1036 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
R1037 VRD-RA2BE101J R 100 1/8W Carbon AB
R1038 VRD-RA2BE101J R 100 1/8W Carbon AB
R1039 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
R1040 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1041 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1043 VRS-CY1JF153J R 15k 1/16W Metal Oxide AA
R1044 VRS-CY1JF153J R 15k 1/16W Metal Oxide AA
R1045 VRD-RA2BE271J R 270 1/8W Carbon AA
R1046 VRD-RA2BE101J R 100 1/8W Carbon AB
R1065 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R1067 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
BALUNES
FB306 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB501 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB502 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB602 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB701 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB702 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB751 RBLN-0037CEZZ R Balun, BLN-0037CE AB
FB752 RBLN-0037CEZZ R Balun, BLN-0037CE AB
SWITCHES
å S701 QSW-P0591CEZZ R Switch AQ
S1001 QSW-K0077GEZZ R Switch, CH Up AB
S1002 QSW-K0077GEZZ R Switch, CH Down AB
S1003 QSW-K0077GEZZ R Switch, Vol Up AB
S1004 QSW-K0077GEZZ R Switch, Vol Down AB
S1005 QSW-K0077GEZZ R Switch, Picture Preset AB
MISCELLANEOUS PARTS
å ACC701 QACCJ9001CESB AC Cord
å QPLGA0201SE0F R AC Plug AG
å QSOCN0243GEZZ Socket
QTIPM0090GEZZ Tip
å FH701 QFSHD1014CEZZ R Fuse Holder AC
å FH702 QFSHD1013CEZZ R Fuse Holder AC
å F701 QFS-C3229CEZZ R Fuse, T3.15A 250V AD
J402 QJAKE0158CEZZ R Jack(14U20/14U25) AF
J403 QJAKE0159CEZZ R Jack, AV-2 In AF
(14U20/14U25)
J405 QJAKH0102PEZZ Jack, AV-1 In
J406 QJAKF0048CEZZ R Jack, Sub Woofer Out AG
P301 QPLGN0441CEZZ R Plug, 4 Pin AB
P303 QPLGN0541CEZZ R Plug, 5 Pin(14U20/25) AB
P305 QPLGN0341CEZZ R Plug, 3 Pin AA
P407 QPLGN0341CEZZ R Plug, 3 Pin AA
P502 QPLGN0560CEZZ R Plug, 5 Pin AC
P602 QPLGN0641CEZZ R Plug, 6 Pin AB
P701 QPLGN0260CEZZ R Plug, 2 Pin AC
P712 QPLGN0269GEZZ R Plug, 2 Pin AB
P1001 QPLGN0541CEZZ R Plug, 5 Pin AB
P1002 QPLGN0541CEZZ R Plug, 5 Pin AB
RDA501 PRDAR0283PEFW R Heat Sink, IC501 AF
RDA701 PRDAR0260PEFW R Heat Sink, IC701 AH
RDA754 PRDAR0224PEFW R Heat Sink, Q602 AF
RDA756 PRDAR0248PEFW R Heat Sink, IC301 AF
RMC1001 RRMCU0235CEZZ R Remote Receiver AK
LHLDP1066PE00 R Holder AC
TP201 QLUGP0102PEZZ R Lug AA
PWB-B DUNTK9990WEZ4 CRT UNIT
TRANSISTORS
Q870 VSBF422////-1 R BF422 AC
Q871 VSBF422////-1 R BF422 AC
Q872 VSBF422////-1 R BF422 AC
Q883 VSBF421////-1 R BF421 AC
Q885 VSBF421////-1 R BF421 AC
Q887 VSBF421////-1 R BF421 AC
DIODES
D811 VHD1SS119//-1 R 1SS119 AB
D812 VHD1SS119//-1 R 1SS119 AB
D880 VHD1SS119//-1 R 1SS119 AB
D881 VHD1SS119//-1 R 1SS119 AB
D882 VHD1SS119//-1 R 1SS119 AB
D883 VHD1SS82///1A R 1SS82 AC
D884 VHD1SS82///1A R 1SS82 AC
D885 VHD1SS82///1A R 1SS82 AC
D886 VHD1SS82///1A R 1SS82 AC
D887 VHD1SS82///1A R 1SS82 AC
D888 VHD1SS82///1A R 1SS82 AC
CAPACITORS
C871 VCKYPA1HB471K R 470p 50V Ceramic AA
C872 VCKYPA1HB471K R 470p 50V Ceramic AA
C873 VCKYPA1HB471K R 470p 50V Ceramic AA
C875 VCKYPA2HB102K R 1000p 500V Ceramic AA
C876 RC-KZ0150CEZZ R 1000p 3kV Ceramic AB
C878 VCEAGA2EW106M R 10 250V Electrolytic AC
C880 VCKYPA1HB471K R 470p 50V Ceramic AA
C881 VCKYPA1HB471K R 470p 50V Ceramic AA
C882 VCKYPA1HB471K R 470p 50V Ceramic AA
RESISTORS
R879 VRD-RA2BE471J R 470 1/8W Carbon AA
R880 VRD-RA2BE471J R 470 1/8W Carbon AA
R881 VRD-RA2BE471J R 470 1/8W Carbon AA
R882 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R883 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R884 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R885 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R886 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R887 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R888 VRD-RA2BE471J R 470 1/8W Carbon AA
R892 VRD-RA2BE102J R 1k 1/8W Carbon AA
R893 VRD-RA2BE102J R 1k 1/8W Carbon AA
R894 VRD-RA2BE102J R 1k 1/8W Carbon AA
R898 VRD-RA2BE471J R 470 1/8W Carbon AA
R899 VRD-RA2BE471J R 470 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0641CEZZ R Plug, 6 Pin AB
P882 QPLGN0541CEZZ R Plug, 5 Pin AB
å SC881 QSOCV0842CEZZ R Socket, 9 Pin AH
PWB-C DUNTK9989WEV1 HEADPHONE UNIT(14U20/25)
RESISTORS
RJ1 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ7 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ8 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R354 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
R355 VRS-CY1JF471J R 470 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J351 QJAKJ0047CEZZ R Jack AD
P351 QPLGN0441CEZZ R Plug, 4 Pin AB
MISCELLANEOUS PARTS
SP301 PSPAH0011KM00 Spacer
SP302 PSPAH0022KM00 Spacer
