Ref. No. Part No. Description Code Ref. No. Part No. Description Code
20
20MR10
PICTURE TUBE
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
MARK : SPARE PARTS-DELIVERY SECTION
MARK : X- RAY RELATED PARTS
Ref. No. Part No. Description Code
V101 VB48KRD89X/3E X Picture Tube BY
DY601 RCiLH0100MEZZ X Deflection Yoke AY
L703 RCiLG0108GJZZ X Degaussing Coil AQ
or
RCiLG0014MEZZ
or
RCiLG0099PEZZ
LHLDW0102GJKZ X Holder AC
LHLDW1007MEKZ X Holder AD
PMAGF3046CEZZ R Purity Magnet AF
QEARC2016PEZZ J Grounding Strap A G
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKA358WEX0 – MAIN Unit —
PWB-B DUNTKA359WEW3 – CRT Unit —
PWB-A: DUNTKA358WEX0
MAIN UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU51 VTUVTST5UF770 R Tuner AZ
or
VTUENV56D82-1
INTEGRATED CIRCUITS
IC201 RH-iX3354CEZZ J LA76843 AT
or
RH-iX3354CEN1
IC351 VHiAN7511//-1 J AN7511 AK
IC501 VHiLA7840//-1 J LA7840 AR
IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
IC702 RH-FX0034CEZZ J PC817 AE
IC771 VHiKA7805AP-1 J KA7805API AE
or
VHiTA7805S/-1
IC2001 RH-iX3492CEZZQ X TMPA8700CPF AT
IC2040 VHiPST994C/-1 J PST994C AD
IC2102 VHiBR2416E2-1 J BR2416E2 AK
or
VHiM24C16B/-1 J M24C16B (IC2101) AG
TRANSISTORS
Q101 VS2SC945AQ/-1 J 2SC945AQ AB
or
VS2SC3198Y/-1
Q201 VS2SC2735//1E J 2SC2735 AC
Q451 VS2SA1530R/-1 J 2SA1530AR AB
Q452 VS2SA1266-Y-1 J 2SA1266-Y AA
Q601 VS2SC2482//-1 J 2SC2482 AD
Q602 VS2SD2586//1E J 2SD2586 AM
Q631 VS2SC945AQ/-1 J 2SC945AQ AB
or
VS2SC3198Y/-1
Q701 VSSPP04N60C-1 J FET AH
or
VSSPP07N60C-1
or
VS2SK2708//1E
or
VS2SK2645++-1
or
VSSTP6NC60+-1
or
VSSTP6NC60F-1
COMBINATION
IC201 RH-iX3354CEZZ RH-iX3354CEN1
C211 VCKYCY1HB102K(1000p) —
C301 VCCCCY1HH470J(47p) VCCCCY1HH220J(22p)
C304 VCCCCY1HH470J(47p) VCCCCY1HH220J(22p)
C802 — VCEA0A1CW106M(10µ(16V))
R209 VRS-CY1JF123J(12k) VRS-CY1JF000J(0)
R302 VRS-CY1JF332J(3.3k) VRS-CY1JF152J(1.5k)
R413 VRS-CY1JF152J(1.5k) VRS-CY1JF222J(2.2K)
!
!
!
!
!
!
!
!
!
!
!
To Next Page
