Sharp 21S-FX10F User Manual

21S-FX10F/10S/10N/10U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PICTURE TUBE
!
VB51QGT420X2E R ITC Picture Tube ( 21S-FX10F / 21S-FX10S )
!
VB51QGT420X1E R ITC Picture Tube ( 21S-FX10N )
!
VB51QGT420X5E R ITC Picture Tube ( 21S-FX10U )
!
RCILGA163WJZZ R Degaussing Coil
QEARCA052WJZZ R Ground-Part
[2] PRINTED WIRING BOARD ASSEMBLIES
DUNTKE439WEA5 - - MAIN Unit ( 21S-FX10F )
DUNTKE439WEA4 - - MAIN Unit ( 21S-FX10S )
DUNTKE439WEA2 - - MAIN Unit ( 21S-FX10N )
DUNTKE439WEA3 - - MAIN Unit ( 21S-FX10U )
DUNTKE440WEA5 - - CRT Unit ( 21S-FX10F )
DUNTKE440WEA4 - - CRT Unit ( 21S-FX10S )
DUNTKE440WEA2 - - CRT Unit ( 21S-FX10N )
DUNTKE440WEA3 - - CRT Unit ( 21S-FX10U )
DUNTKE442WEA5 - - SURROUND Unit ( 21S-FX10F )
DUNTKE442WEA4 - - SURROUND Unit ( 21S-FX10S )
DUNTKE442WEA2 - - SURROUND Unit ( 21S-FX10N )
DUNTKE442WEA3 - - SURROUND Unit ( 21S-FX10U )
[3] MAIN UNIT
!
TU201 RTUNQA046WJZZ AT R Tuner ( 21S-FX10N / 21S-FX10U Only )
TU201 RTUNQA039WJZZ R Tuner ( 21S-FX10F / 21S-FX10S Only )
IC301 VHILA42102+-1 R I.C.
!
IC501 VHILA78041+-1 R I.C.
!
IC701 VHISTRW6553-1 AM R I.C.
IC702 RH-FXA003WJZZ R I.C.
IC703 VHISE125N++-F R I.C.
IC751 VHIKIA78D33-1 R I.C.
IC752 VHIPQ05RDA1-1 R I.C.
IC1001 RH-IXC324WJZZQ R I.C.
IC1003 VHIM24C16W6-1Y R I.C.
Q201 VS2SC2735//-1Y R 2SC2735 ( 21S-FX10F / 21S-FX10S Only )
Q202 VS2SC3928AR-1Y AB R 2SC3928AR ( 21S-FX10F / 21S-FX10S Only )
Q302 VS2SA1530AR-1Y AB R 2SA1530AR
Q601 VS2SC2235Y/1E+ AE R 2SC2235
Q602 VS2SC6090++1E R 2SC6090++
Q603 VS2SC3198-G-1+ AA R 2SC3198
Q604 VS2SK2161++-1 R 2SK2161++
Q801 VS2SC3928AR-1Y AB R 2SC3928AR
Q803 VS2SC3928AR-1Y AB R 2SC3928AR
Q1070 VS2SC3928AR-1Y AB R 2SC3928AR
D201 VHEZJ33C+++1EY R Diode
D202 VHD1SS356//-1Y R Diode ( 21S-FX10F / 21S-FX10S Only )
D203 VHDHSS4148+-1Y AA R Diode
D301 VHEZJ12B+++1EY R Diode
D302 VHDHSS4148+-1Y AA R Diode
D303 VHDHSS4148+-1Y AA R Diode
D392 RH-DX0445CEZZ AC R Diode, DX0445CE
D505 RH-DX0441CEZZY AC R Diode, DX0441CE
D510 RH-DX0302CEZZY AC R Diode, DX0131CE
D511 RH-DX0302CEZZY AC R Diode, DX0131CE
D602 VHD1SS244//-1Y AB R Diode ,1SS244
D603 RH-EXA572WJZZY R Zener Diode
D605 VHDHSS4148+-1Y AA R Diode
D606 RH-DX0131CEZZY AC R Diode, DX0131CE
D607 VHDHSS4148+-1Y AA R Diode
D608 VHEZJ6R2A++1EY R Zener Diode
D609 RH-DX0321CEZZY R Diode ,DX0321CE
D610 RH-DX0255CEZZ R Diode ,DX0255CE
D611 RH-DXA006WJZZ AD R Diode, DXA006WJ
!
D701 RH-DX0476CEZZ AG R Diode, DX0476CE
D706 RH-DX0066GEZZY AC R Diode, DX0066GE
D709 RH-DX0066GEZZY AC R Diode, DX0066GE
D714 VHDHSS4148+-1Y AA R Diode
D716 VHEZJ2R0B++1EY R Zener Diode
D724 VHEZJ4R3B++1EY R Zener Diode
D725 VHDHSS4148+-1Y AA R Diode
D751 RH-DXA006WJZZ AD R Diode, DXA006WJ
D752 RH-DX0247CEZZ AE R Diode, DX0247CE
D760 VHEZJ8R2B++1EY R Zener Diode
D801 RH-EXA578WJZZY R Zener Diode 33V
D802 RH-EXA578WJZZY R Zener Diode 33V
D803 RH-EXA578WJZZY R Zener Diode 33V
D804 VHDHSS4148+-1Y AA R Diode
D806 RH-EXA520WJZZY R Zener Diode 5.1V
D807 VHEZJ5R1B++1EY R Zener Diode
D808 VHEZJ27B+++1EY R
D1001 RH-PX0013PEZZ AC R Photodiode
D1003 RH-EXA520WJZZY R Zener Diode 5.1V
D1004 RH-EXA520WJZZY R Zener Diode 5.1V
D1005 VHDHSS4148+-1Y AA R Diode
D1007 VHDHSS4148+-1Y AA R Diode
NR701 RH-HXA013WJZZ+ R Thermistor
