21S-FX10F/10S/10N/10U
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1028 VRD-RA2BE181JY AA R 180 1/8W Carbon
R1033 VRD-RA2BE332JY AA R 3.3K 1/8W Carbon
R1034 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1035 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1036 VRS-CY1JF122JY AA R 1.2K 1/16W Metal Oxide
R1037 VRS-CY1JF222JY AA R 2.2K 1/16W Metal Oxide
R1038 VRS-CY1JF152JY AA R 1.5K 1/16W Metal Oxide
R1039 VRS-CY1JF152JY AA R 1.5K 1/16W Metal Oxide
R1040 VRS-CY1JF223JY AA R 22K 1/16W Metal Oxide ( 21S-FX10F / 10S Only )
R1041 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1042 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1043 VRD-RM2HD102JY AA R 1 500V Carbon
R1045 VRS-CY1JF151JY AA R 150 1/16W Metal Oxide
R1046 VRS-CY1JF151JY AA R 150 1/16W Metal Oxide
R1047 VRS-CY1JF151JY AA R 150 1/16W Metal Oxide
R1050 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1051 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1052 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1053 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1054 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1055 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1056 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1057 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1058 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1059 VRD-RA2BE151JY AA R 150 1/8W Carbon
R1078 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1079 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R3001 VRS-CY1JF750JY AA R 75 1/16W Metal Oxide
S701 QSW-PA003WJZZ AG R Switch , POWER
S1001 QSW-KA019WJZZ+ AC R Switch , CH UP
S1002 QSW-KA019WJZZ+ AC R Switch , CH DOWN
S1003 QSW-KA019WJZZ+ AC R Switch , VOL UP
S1004 QSW-KA019WJZZ+ AC R Switch , VOL DOWN
S1005 QSW-KA019WJZZ+ AC R Switch , MENU
!
F701 QFS-C3225CEZZ AC R Fuse , 3.15A 250V
FH701 QFSHD1013CEZZ+ AC R Fuse Holder
FH702 QFSHD1014CEZZ+ AC R Fuse Holder
J3 VW7UGB-190KK R Jumper Wire
J351 QJAKJA020WJZZ R Jack
J401 QJAKGA083WJZZ R Jack
J402 QJAKEA056WJ04 R Jack
J403 QJAKEA056WJ09 R Jack
J404 QJAKEA070WJ02 R Jack
J405 QTANJA136WJZZ R Jack
JA443 QJUM-0001AJFWY R Jumper Wire ( 21S-FX10F / 21S-FX10S Only )
P302 QPLGN0461CEZZA AB R Plug , 4Pin (S)
P310 QPLGNA107WJZZ R Plug
P601 QPLGN0660CEZZ AC R Plug , 6Pin (F)
P602 LHLDW1104PEZZ AB R Plug
P701 QPLGN0260CEZZ AC R Plug ,2Pin (M)
P702 QPLGN0269GEZZ AB R Plug ,2Pin
P1001 LHLDW1105PEZZ AB R Plug
P1002 QPLGNA110WJZZ AB R Plug
P1005 QSOCN0257FJ00 R Socket 8pin
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
RDA301 PRDARA418WJFW AC R Heat Sink for IC301
RDA392 PRDARA181WJFW R Heat Sink for D392
RDA501 PRDARA545WJFW AD R Heat Sink for IC501
RDA602 PRDARA361WJFW R Heat Sink for Q602
RDA604 PRDARA361WJFW R Heat Sink for Q604
RDA701 PRDARA119WJFW AF R Heat Sink for IC701
RDA751 PRDARA181WJFW R Heat Sink for IC751
RDA752 PRDARA167WJFW R Heat Sink for IC752
[4] CRT UNIT
IC851 VHITDA6107A-1 R I.C.
D851 RH-DX0443CEZZY R Diode
D852 RH-DX0443CEZZY R Diode
D853 RH-DX0443CEZZY R Diode
C851 VCKYPA1HB561K+ AA R 560p 50V Ceramic
C852 VCKYPA1HB391K+ AA R 390p 50V Ceramic
C854 RC-KZ018JCEZZ R 10000pf 250V Porcelain
C856 VCKYPA2HB102K+ AB R 1 500V Ceramic
C861 VCKYPA2HB561K+ AB R 560p 500V Ceramic
C862 VCKYPA2HB102K+ AB R 1 500V Ceramic
C863 VCKYPA2HB102K+ AB R 1 500V Ceramic
C851 RC-FZA295WJZZ+ R 0.082u 250v Metalic Plastic Film
C852 VCEA0A2EW106M+ AB R 10 250V Electrolytic
R851 VRD-RM2HD101JY AA R 100 500V Carbon
R852 VRD-RM2HD101JY AA R 100 500V Carbon
R853 VRD-RM2HD101JY AA R 100 500V Carbon
R854 VRC-MA2HG152KY R 1.5K 0.5W Solid
R855 VRC-MA2HG152KY R 1.5K 0.5W Solid
R856 VRC-MA2HG152KY R 1.5K 0.5W Solid
[3] MAIN UNIT
