PARTS GUIDE
No. SZ8M224T-C6070AH1X
LED BACKLIGHT TV
MODEL
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
4T-C6070AH1X
:4T-C60AH1X
:4T-C70AH1X
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] MAIN UNIT ( DKEYMG924FM01/02
) 4T-C60/70AH1X
[4] CABINET & MECHANICAL PARTS
4T-C60AH1X
[5] CABINET & MECHANICAL PARTS
4T-C70AH1X
[6] SUPPLIED ACCESSORIES 4T-
C60AH1X
[7] SUPPLIED ACCESSORIES 4T-
C70AH1X
[8] PACKING PARTS NOT REPLACE-
MENT ITEM 4T-C60AH1X
[9] PACKING PARTS NOT REPLACE-
MENT ITEM 4T-C70AH1X
