ELECTRICAL PARTS
For Model AH-X108E and AU-X108E
DESCRIPTION MODEL REMARKS SITE
Indoor fan motor ML-A486 220 - 240V, 50Hz AH
Indoor fan motor capacitor – 430V, 1.5µF AH
Transformer – Primary; AC 230V, 50Hz AH
Secondary; AC14.5V, 50Hz
Fuse – 250V, 2.5A AH
Compressor HV237A1-S15DK 3-PHASE Induction motor AU
Outdoor fan motor ML-A720 220 - 240V, 50Hz AU
Outdoor fan motor capacitor – 430V, 2.0µF AU
WPE1 – QFS-GA015JBE0(10A, 250V) AU
WPE2 – QFS-AA047JBE0(13A, 250V) AU
WPE3 – QFS-GA008JBE0(3A, 250V) AU
For Model AY-X108E and AE-X108E
DESCRIPTION MODEL REMARKS SITE
Indoor fan motor ML-A486 220 - 240V, 50Hz AY
Indoor fan motor capacitor – 430V, 1.5µF AY
Transformer – Primary; AC 230V, 50Hz AY
Secondary; AC14.5V, 50Hz
Fuse – 250V, 2.5A AY
Compressor HV237A1-S15DK 3-PHASE Induction motor AE
Outdoor fan motor ML-A719 220 - 240V, 50Hz AE
Outdoor fan motor capacitor – 430V, 2.0µF AE
WPE1 – QFS-GA015JBE0(10A, 250V) AE
WPE2 – QFS-AA047JBE0(13A, 250V) AE
WPE3 – QFS-GA008JBE0(3A, 250V) AE
