Sharp AE-X138E User Manual

AH/AU-X108E
AY/AE-X108E
AH/AU-X138E
AY/AE-X138E
46
REPLACEMENT PARTS LIST
[AH-X108E/AH-X138E/AY-X108E/AY-X138E]
CABINET AND UNIT PARTS
1- 1 CMOT-A263JBK0 Fan motor sub ass'y 1 BK
1- 2 PGUMMA071JBE0 Motor cushion 1 AN
1- 3 CHLD-A050JBK0 Bearing ass'y 1 AG
1- 4 DCHS-A332JBK0 Cabinet ass'y 1 AY
1- 5 NFANCA066JBE0 Cross flow fan 1 AW
1- 6 CSRA-A433JBK0 Drain pan ass'y 1 BG
1- 7 GGAD-A032JBTA Fan guard 1 AT
1- 8 MJNTPA062JBFA Louver link 2 AD
1- 9 MLOV-A199JBFA Vertical adjustment louver A 8 AK
1-10 MLOV-A201JBFA Vertical adjustment louver R 1 AK
1-11 MLOV-A211JBFA Vertical adjustment louver L 1 AC
1-12 MLOV-A215JBFA Vertical adjustment louver B 2 AC
1-13 MLOV-A204JBFA Horizontal adjust. louver A 1 AK
1-14 MLOV-A205JBFA Horizontal adjust. louver B 1 AK
1-15 LHLD-A197JBFP Louver holder 2 AC
1-16 MARMPA037JBF0 Side clamp A 1 AC
1-17 MARMPA038JBF0 Side clamp B 1 AC
1-18 MARMPA039JBF0 Side clamp C 1 AC
1-19 MARMPA040JBF0 Side clamp D 2 AD
1-20 NBRG-A026JBFA Louver bushing 4 AB
1-21 LHLD-A410JBFA Display holder 1 AE
1-22 CHOS-A004JBK0 Drain hose ass'y 1 AM
1-23 PPACGA010JBE0 O ring 1 AB
1-24 DCOV-A159JBFA Drain pan cover 1 AL
1-25 RMOT-A061JBE0 Louver motor 1 AS
1-26 PGUMMA110JBE0 Drain cap 1 AD
1-27 CWAK-B804JBK0 Front panel ass'y 1 BB
1-28 CPNL-A272JBK0 Open panel ass'y 1 AT
1-29 HBDG-A059JBEA Badge 1 AF
1-30 CDEC-A060JBE0 Display cover ass'y 1 AK
1-31 FCOV-A031JBFA Recieving filter 1 AE
1-32 PFILMA107JBEA Air filter 2 AM
1-33 LHLD-A302JBFA Tube holder 1 AD
1-34 LHLD-A303JBFA Tube holder 1 AD
1-35 PGUMMA082JBE0 Motor cushion 1 AD
1-36 GWAK-A245JBFA Front panel 1 AV
1-37 PCOV-A323JBF0 Drain cover 1 AE
1-38 TLABCB070JBR0 Wiring diagram 1 AE
1-39 TSPC-C715JBR0 Name badge [AH-X108E] 1 AE
1-39 TSPC-C713JBR0 Name badge [AY-X108E] 1 AE
1-39 TSPC-C711JBR0 Name badge [AH-X138E] 1 AG
1-39 TSPC-C702JBR0 Name badge [AY-X138E] 1 AE
1-40 TLABKC209JBR0 Number card [AH-X108E] 1 AC
1-40 TLABKC206JBR0 Number card [AY-X108E] 1 AC
1-40 TLABKC208JBR0 Number card [AH-X138E] 1 AC
1-40 TLABKC207JBR0 Number card [AY-X138E] 1 AC
1-41 QW-VZC597JBE0 Louver motor wire 1 AN
1-42 QW-VZC406JBE0 Fan motor wire 1 AK
1-43 PFPFPB269JBE0 Panel insulator 1 AB
1-44 PSPA-A102JBE0 Rubber spacer 1 AD
CONTROL BOX
2- 1 LHLD-A281JBFA Cord holder 1 AC
2- 2 PBOX-A229JBF0 Control box 1 AN
2- 3 LHLD-A353JBFA Terminal board holder 1 AD
2- 4 LHLD-A354JBFA Cord holder 1 AD
2- 5 LHLD-A282JBF0 Thermistor holder 1 AG
2- 6 CPNL-A276JBK0 Cont. box cover ass'y 1 AN
2- 7 HPNLCA728JBEA Control panel 1 AD
2- 8 PCOV-A483JBFA LED holder 1 AE
2- 9 DSGY-A940JBK0 Electric control board [AH-X108E] 1 BG
2- 9 DSGY-A934JBK0 Electric control board [AY-X108E] 1 BG
2- 9 DSGY-A933JBK0 Electric control board [AH-X138E] 1 BG
2- 9 DSGY-A916JBK0 Electric control board [AY-X138E] 1 BP
2-10 PCOV-A386JBF0 Thermo holder cover 1 AD
2-11 QACC-A219JBE0 Power supply cord 1 AQ
2-12 QTAN-A152JBE0 Terminal board 1 AN
2-13 QTAN-A186JBE0 4Poles terminal board 1 AP
2-14 LPLTMA143JBP0 Control box angle 1 AE
2-15 PSEL-B542JBE0 Aluminum tape 1 AD
2-16 PSHE-A169JBE0 Protect sheet 1 AC
2-17 RTHM-A300JBE0 Thermistor 1 AN
REF. NO. PART NO. DESCRIPTION Q'TY CODE
