LC-52/60/70LE640U/C6400U,LC-80LE633U/844U (1st Edition)
4 – 30
[7] Precautions for assembly (LC-52/60/70LE640U/C6400U)
1. Points to be checked and precautions when servicing the unit
Mount the main PWB Ass’y on the backlight chassis and check that the EMI-prevention parts are not peeled and twisted from the access holes. (The
EMI-prevention parts, conductive nonwoven fabric gaskets, must be seen from the access holes.)
[Countermeasure]
Attach the conductive nonwoven fabric gaskets on the shielded case on the main PWB.
• LC-52/60LE640U,C6400U
PSPA Z C69 0 WJZ Z
PSPA Z C69 1 WJZ Z x 2
PSPA Z C69 1 WJZ Z
To Next Page
