LC-52/60/70LE640U/C6400U,LC-80LE633U/844U (1st Edition)
iv
LC52LE640U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: • LC-52/60/70LE640U,C6400U
*1 Replace MAIN PWB Units (DKEYMF733FM**) in case of IC8401, IC3303 or IC8455 failure.
*2 Replace LCD CONTROL Units (DUNTKA975FM**) in case of IC5803 failure.
• LC-80LE633U
*1 Replace MAIN PWB Units (DKEYMF733FM**) in case of IC8401, IC3303, IC8455 or IC5803 failure.
• LC-80LE844U
*1 Replace MAIN PWB Units (DKEYMF953FM**) in case of IC3103 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref No. Parts No. Description
N DKEYMF733FM82 MAIN Unit (LC-52/60/70LE640U,C6400U,LC-80LE633U)
N DKEYMF953FM01 MAIN Unit (LC-80LE844U)
N DUNTKF800FM53 KEY Unit
N DUNTKF975FM01 LCD CONTROL Unit (LC-52/60/70LE640U,C6400U)
N DUNTKF975FM07 LCD CONTROL Unit (LC-80LE633U)
N DUNTKF961FM07 LCD CONTROL Unit (LC-80LE844U)
N DUNTKG014FM01 ICON Unit (LC-52/60/70LE640U,C6400U)
N DUNTKF770FM02 ICON Unit (LC-80LE633U)
N DUNTKF770FM03 ICON Unit (LC-80LE844U)
N DUNTKG015FM01 R/C OPC Unit (LC-52/60/70LE640U,C6400U)
N DUNTKF494FM01 R/C OPC Unit (LC-80LE633U/844U)
N RUNTKA936WJQZ Wi-Fi Unit
N RUNTKA931WJQZ POWER/DRIVE Unit (LC-52LE640U/C6400U)
N RUNTKA932WJQZ POWER/DRIVE Unit (LC-60LE640U/C6400U)
N RUNTKA933WJQZ POWER/DRIVE Unit (LC-70LE640U/C6400U)
N RUNTKA903WJN1 POWER/LED DRIVE Unit (LC-80LE633U/844U)
N RUNTKA819WJQZ 3D-IR Unit (LC-80LE844U)
Ref No. Parts No. Description
N R1LK520D3GV00Z 52" LCD Panel Module Unit (LC-52LE640U/C6400U) (LK520D3GV00Z)
N R1LK600D3GV00Z 60" LCD Panel Module Unit (LC-60LE640U/C6400U) (LK600D3GV00Z)
N R1LK695D3GW80D 70" LCD Panel Module Unit (LC-70LE640U/C6400U) (LK695D3GW80D)
N R1LK800D3GW10Z 80" LCD Panel Module Unit (LC-80LE633U) (LK800D3GW10Z)
N R1LK800D3GW40Z 80" LCD Panel Module Unit (LC-80LE844U) (LK800D3GW40Z)
Ref No. Parts No. Description Q’ty
IC2001 RH-iXD241WJNSQ IC R5F21368CNFP (Monitor Microprocessor) (LC-52/60/70LE640U,C6400U,LC-80LE633U) 1
IC2001 RH-iXD241WJNUQ IC (Monitor Microprocessor) (LC-80LE844U) 1
Ref No. Parts No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control to LCD Panel, x2 2
N QCNW-M580WJQZ
Connecting Cord L=1000mm 41pins, Main to LCD Control (LW) (LC-52/60/70LE640U,C6400U,LC-
80LE633U)
1
N QCNW-L795WJQZ
Connecting Cord L=1000mm 24pins, Main to Power (PD) (LC-52/60/70LE640U,C6400U,LC-
80LE633U)
1
N QCNW-L807WJQZ Connecting Cord L=1000mm 4pins, Main to LCD Control(PL) (LC-52/60/70LE640U,C6400U) 1
N QCNW-G405WJQZ Connecting Cord L=1000mm 4pins, Main to LCD Control(PL) (LC-80LE633U) 1
N QCNW-L214WJQZ Connecting Cord L=1000mm 64pins, LCD Control to LCD Panel (LC-80LE844U) 2
N QCNW-M580WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control (LV) (LC-80LE844U) 1
N QCNW-M539WJQZ Connecting Cord L=1000mm 24-24-4pins, Main to Power to LCD Control(PD) (LC-80LE844U) 1
