Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
64
LC-20S1E
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which does no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
LCD PANEL
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKB983WE03 – INVERTER Unit —
DUNTKB984WE03 – TUNER Unit —
DUNTKB985WE03 – R/C,LED Unit —
DUNTKB988FE03 – MAIN Unit —
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA025WJZZ J 20" LCD Panel Unit DB
DUNTKB983WE03
INVERTER UNIT
TRANSISTORS
Q6700 VS2SC5886++-1Y J 2SC5886 AE
Q6701 VS2SC5886++-1Y J 2SC5886 AE
Q6702 VS2SA1530AR-1Y J 2SA1530AR AB
Q6703 VS2SC5886++-1Y J 2SC5886 AE
Q6704 VS2SC5886++-1Y J 2SC5886 AE
Q6705 VS2SA1530AR-1Y J 2SA1530AR AB
Q6706 VSUPA606T//-1Y J UPA606T AD
Q6707 VS2SC5886++-1Y J 2SC5886 AE
Q6708 VS2SC5886++-1Y J 2SC5886 AE
Q6709 VS2SA1530AR-1Y J 2SA1530AR AB
Q6710 VS2SC5886++-1Y J 2SC5886 AE
Q6711 VS2SC5886++-1Y J 2SC5886 AE
Q6712 VS2SA1530AR-1Y J 2SA1530AR AB
Q6713 VSUPA606T//-1Y J UPA606T AD
Q6714 VS2SC5886++-1Y J 2SC5886 AE
Q6715 VS2SC5886++-1Y J 2SC5886 AE
Q6716 VS2SA1530AR-1Y J 2SA1530AR AB
Q6717 VSUPA606T//-1Y J UPA606T AD
DIODES
D6700 VHDDAN202K/-1Y J Diode AB
D6701 VHDDAN202K/-1Y J Diode AB
D6702 VHDMA157A//-1Y J Diode AC
D6703 VHDMA157A//-1Y J Diode AC
D6704 VHDDAN202K/-1Y J Diode AB
D6705 VHDDAN202K/-1Y J Diode AB
D6707 VHDMA157A//-1Y J Diode AC
D6708 VHDMA157A//-1Y J Diode AC
D6709 VHDDAN202K/-1Y J Diode AB
D6710 VHDMA157A//-1Y J Diode AC
D6711 VHDDAN202K/-1Y J Diode AB
COILS
L6700 RCiLPA034WJZZ J Coil AD
L6701 RCiLPA034WJZZ J Coil AD
L6702 RCiLPA034WJZZ J Coil AD
L6703 RCiLPA034WJZZ J Coil AD
L6704 RCiLPA034WJZZ J Coil AD
TRANSFORMERS
å T6700 RTRNZA031WJZZQ J Transformer AQ
å T6701 RTRNZA032WJZZQ J Transformer AQ
å T6702 RTRNZA032WJZZQ J Transformer AQ
å T6703 RTRNZA032WJZZQ J Transformer AQ
å T6704 RTRNZA031WJZZQ J Transformer AQ
CAPACITORS
C6700 RC-FZA125WJZZ J 0.09 250V Film AD
C6701 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6703 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6704 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6705 RC-FZA125WJZZ J 0.09 250V Film AD
C6706 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6708 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6709 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6710 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6711 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6712 RC-FZA125WJZZ J 0.09 250V Film AD
C6713 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6715 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6716 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6717 RC-FZA125WJZZ J 0.09 250V Film AD
C6718 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6720 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6721 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6722 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6723 RC-KZ0072TAZZY J 1 25V Ceramic AC
C6724 RC-FZA125WJZZ J 0.09 250V Film AD
C6725 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6727 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6728 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6729 RC-KZ0072TAZZY J 1 25V Ceramic AC
RESISTORS
R6700 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6701 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6702 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6703 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6704 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6705 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6706 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6707 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6708 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R6709 VRS-CY1JF824JY J 820k 1/16W Metal Oxide AA
R6710 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R6711 VRS-CY1JF824JY J 820k 1/16W Metal Oxide AA
R6712 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R6713 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R6714 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6715 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6716 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6717 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6718 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6719 VRS-TW2ED122JY J 1.2k 1/4W Metal Oxide AA
R6720 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R6721 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6722 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
