Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
70
LC-20S1E
DUNTKB988FE03
MAIN UNIT
INTEGRATED CIRCUITS
IC702 VHiBA05FP++-1Y J BA05FP-E2 AF
IC704 VHiNJ79M08D-1Y J NJM79M08DL1A AF
IC705 VHiNJU7662M-1Y J NJU7662M(TE2) AL
IC706 VHiPQ1R34++-1Y J PQ1R34 AE
IC707 VHiPQ1R33//-1Y J PQ1R33 AE
IC708 VHiLM1117MJ-1Y J LM1117MPX-ADJ AF
IC709 VHiMM1562FF-1Y J MM1562FFBE AE
IC710 VHiMM1563DF-1Y J MM1563DFBE AE
IC801 VHiVPC3230D1EQ J VPC3230D-QA-B3 BD
IC802 VHiNJM2293M-1Y J NJM2293M(TE1) AG
IC803 VHiNJM2268M-1Y J NJM2268M-TE1 AF
IC804 VHiBA7046F/-1Y J BA7046F AF
IC805 VHiNJM2233V-1Y J NJM2233V AE
IC806 VHiMM1563DF-1Y J MM1563DFBE AE
IC1101 VHiBD8120FP-1Y J BD8120FP AX
IC1201 VHiDPS9450+-1Q J DPS9450A-XZ-A1 BD
IC1202 VHiTC4W66U/-1Y J TC4W66FU AE
IC1601 VHiSDA5550M-1Q J SDA5550M AZ
IC1603 VHiPST3228N1EY J PST3228NR AD
IC1604 VHiMM1501XN-1Y J MM1501XNRE AE
IC1606 VHiPST3221N1EY J PST3221NR AD
IC1608 VHiNC7SZ58P-1Y J NC7SZ58P6X AE
IC1611 RH-iXA745WJN1Q J M29W400BT70N6 AP
IC1612 VHi62S8308X-1Q J A62S8308X-70SI AY
IC2001 RH-iXA661WJZZQ J I.C. BA
IC2003 VHiSi3010KM-1Y J SI-3010KM-TL AF
IC2004 VHiMM1573DN-1Y J MM1573DNRE AD
IC2006 VHiBD4729G+-1Y J BD4729G-TR AD
IC2007 VHiBR24C32F-1Y J BR24C32F-E2 AH
IC2009 VHiBR2416E2-1Y J BR24C16F AK
IC2010 VHiTC4W66U/-1Y J TC4W66FU AE
IC2011 VHiTC4W66U/-1Y J TC4W66FU AE
TRANSISTORS
Q701 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q702 VSDTC144EE/-1Y J DTC144EE AA
Q703 VSFMMT718//-1Y J FMMT718 AE
Q704 VSDTC144EE/-1Y J DTC144EE AA
Q705 VSUMX2N++++-1Y J UMX2N AB
Q801 VS2SA1530AR-1Y J 2SA1530AR AB
Q802 VS2SA1530AR-1Y J 2SA1530AR AB
Q803 VS2SA1530AR-1Y J 2SA1530AR AB
Q1101 VSFMMT718//-1Y J FMMT718 AE
Q1102 VS2SC4520//-1Y J 2SC4520 AE
Q1103 VS2SA1729//-1Y J 2SA1729 AF
Q1104 VSDTC144EE/-1Y J DTC144EE AA
Q1105 VS2SC4520//-1Y J 2SC4520 AE
Q1106 VS2SA1729//-1Y J 2SA1729 AF
Q1206 VSDTC144EE/-1Y J DTC144EE AA
Q1601 VS2SA1530AR-1Y J 2SA1530AR AB
Q1602 VS2SA1530AR-1Y J 2SA1530AR AB
Q1603 VSDTC144TE/-1Y J DTC144EE AB
Q1604 VS2SA1530AR-1Y J 2SA1530AR AB
Q1605 VS2SC3928AR-1Y J 2SC3928AR AB
Q1606 VS2SA1530AR-1Y J 2SA1530AR AB
Q1607 VS2SA1530AR-1Y J 2SA1530AR AB
Q2001 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q2005 VSDTC114EE/-1Y J DTC114EE AB
Q2006 VSDTC114EE/-1Y J DTC114EE AB
Q2007 VSUPA606T//-1Y J UPA606T AD
Q2008 VSDTC114EE/-1Y J DTC114EE AB
Q2009 VSUPA606T//-1Y J UPA606T AD
Q2011 VSUPA606T//-1Y J UPA606T AD
DIODES
D701 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D702 VHDDAN222//-1Y J Diode AA
D703 VHDDAN222//-1Y J Diode AA
D704 RH-EX1245CEZZY J Zener Diode, 5.1V AB
D705 VHDDAN222//-1Y J Diode AA
D706 VHDDAN222//-1Y J Diode AA
D707 VHDDAN222//-1Y J Diode AA
D708 RH-EX1245CEZZY J Zener Diode, 5.1V AB
D709 VHDDAN222//-1Y J Diode AA
D710 VHDDAN202K/-1Y J Diode AB
D711 VHD1SS250//1EY J Diode AB
D712 VHDDAN222//-1Y J Diode AA
D713 VHDRB481K++-1Y J Diode AD
D714 VHDRB491D++-1Y J Diode AD
D1101 VHD1SS250//1EY J Diode AB
D1103 VHD1SS250//1EY J Diode AB
D1104 VHD1SS250//1EY J Diode AB
D2001 RH-EX1232CEZZY J Zener Diode AB
D2002 VHDDAN202K/-1Y J Diode AB
D2003 VHDDAN202K/-1Y J Diode AB
D2004 VHDRB491D++-1Y J Diode AD
PACKAGED CIRCUITS
X801 RCRSC0012CEZZY J Crystal, 20.25MHz AH
X1201 RCRSC0012CEZZY J Crystal AH
X1601 RCRSCA002WJZZY J Crystal AG
FILTER AND COILS
FL801 RFiLJA001WJZZY J Filter AG
FL802 RFiLJA001WJZZY J Filter AG
FL2001 RFiLZ0169TAZZY J Filter AD
L701 RCiLPA143WJZZY J Coil AD
L702 VP-1M470J5R4NY J Peaking 47µH AC
L801 RCiLPA143WJZZY J Coil AD
L802 RCiLPA143WJZZY J Coil AD
L803 VP-9N3R3KR46NY J Peaking 3.3µH AC
L804 VP-9N3R3KR46NY J Peaking 3.3µH AC
L805 VP-9N3R3KR46NY J Peaking 3.3µH AC
L1201 VPCGM220M0R5NY J Peaking 22µH AB
L1202 VPCGM220M0R5NY J Peaking 22µH AB
L1203 VPCGM220M0R5NY J Peaking 22µH AB
L1204 VPCGM220M0R5NY J Peaking 22µH AB
L1601 VP-1M270J3R8NY J Peaking 27µH AC
CAPACITORS
C701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C702 RC-EZA127WJZZY J 100 16V Electrolytic AC
C704 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C705 RC-EZA127WJZZY J 100 16V Electrolytic AC
C707 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C708 VCEASK1CN227MY J 220 16V Electrolytic AC
C709 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C710 VCKYTV1CB105KY J 1 16V Ceramic AC
C711 VCKYTV1CB105KY J 1 16V Ceramic AC
C712 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C713 RC-EZA132WJZZY J 10 50V Electrolytic AC
C714 RC-KZA041WJZZY J 10 10V Ceramic AC
C715 RC-EZA129WJZZY J 2.2 50V Electrolytic AB
C716 VCKYTV1CB105KY J 1 16V Ceramic AC
C717 RC-KZA041WJZZY J 10 10V Ceramic AC
C718 VCKYTV1CB105KY J 1 16V Ceramic AC
C719 RC-KZA041WJZZY J 10 10V Ceramic AC
C720 RC-EZA132WJZZY J 10 50V Electrolytic AC
C721 RC-KZA041WJZZY J 10 10V Ceramic AC
C722 RC-KZA041WJZZY J 10 10V Ceramic AC
C723 RC-EZA132WJZZY J 10 50V Electrolytic AC
C724 VCKYTV1CB105KY J 1 16V Ceramic AC
C725 RC-KZA041WJZZY J 10 10V Ceramic AC
C726 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C727 VCEASH0JN227MY J 220 6.3V Electrolytic AC
C728 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C729 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C730 RC-EZA123WJZZY J 100 6.3V Electrolytic AC
C731 RC-EZA131WJZZY J 4.7 50V Electrolytic AC
C732 RC-KZA030WJZZY J 2.2 10V Ceramic AB
C733 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C734 VCCCCY1HH471JY J 470p 50V Ceramic AA
C735 RC-EZA132WJZZY J 10 50V Electrolytic AC
C736 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C737 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
