Connecting external devices
HDMI connection
Example of connectable devices
E DVDE Blu-rayplayer/recorder
TheHDMIconnections(HighDefinitionMultimedia
Interface)permitdigitalvideoandaudiotransmission
viaaconnectioncablefromaplayer/recorder.The
digitalpictureandsounddataaretransmittedwithout
datacompressionandthereforelosenoneoftheir
quality.Analogue/digitalconversionisnolonger
necessaryintheconnecteddevices,whichalsowould
resultinqualitylosses.
HDMI
DVI
26”
26”
32”
42”
32”
42”
DVI/HDMI conversion
• UsinganDVI/HDMIadaptercable,thedigitalvideo
signalsofaDVDcanalsobeplayedviathecompatible
HDMIconnection.Thesoundmustbefedinadditionally.
• BothHDMIandDVIusethesameHDCPcopy
protectionmethod.
Supported video signal:
576p,480p,1080i,720p,1080p
Seepage26forPCsignalcompatibility.
YPbPr (Component connection)
Example of connectable devices
E VCRE DVDE Blue-rayplayer/recorder
Youwillenjoyaccuratecolourreproductionandhigh
qualityimagesthroughthe(YPbPr)whenconnectinga
DVDrecorderorotherrecordingequipment.

26”
32”
42”
SCART connection
Example of connectable devices
E Decoder
E
When using the SCART 1
FullSCART,whichtransmitsRGB,S-VideoandCVBS
in,andCVBStunerout.
26”
32”
42”
E
Before connecting ���
• BesuretoturnofftheTVandanydevicesbefore
makinganyconnections.
• Firmlyconnectacabletoaterminalorterminals.
• Carefullyreadtheoperationmanualofeachexternal
deviceforpossibleconnectiontypes.Thisalso
helpsyougetthebestpossibleaudiovisualqualityto
maximisethepotentialoftheTVandtheconnected
device.
HDMI device
HDMIcable
DVI-HDMIcable
Audiocable
(YPbPr) Component
Connection
Componentcable
Audiocable
SCARTcable
Decoder
24

Sharp LC-26SH330E Specifications

General

Child lock	No
Teletext function	Yes
Audio formats supported	AAC
Video formats supported	DIVX, MPEG4
Number of AV connections	1
Response time	6.5 ms
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Supported graphics resolutions	1366 x 768
HDMI version	1.3
Audio (L/R) in	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Panel mounting interface	200 x 100 mm
Remote control type	GL220
Power consumption (standby)	0.18 W
Power consumption (typical)	55 W
RMS rated power	10 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-T

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8300 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
