Sharp LC-26SH7E User Manual

Appendix
Item
19o LCD COLOUR TV,
Model: LC-19SH7E
26o LCD COLOUR TV,
Model: LC-26SH7E
32o LCD COLOUR TV,
Model: LC-32SH7E
LCD screen size
19o diagonal 26o diagonal 32o diagonal
Number of dots 3,147,264 dots
(1366 g 768 g 3 dots)
3,147,264 dots
(1366 g 768 g 3 dots)
3,147,264 dots
(1366 g 768 g 3 dots)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
TV-Standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF ATV : IRA-E69, DVB-T : E5-E69
CATV S-band, S1–S41ch
TV-Tuning System Auto Preset 999 ch, Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Viewing angles H : 170° V : 160° H : 160° V : 150° H : 176° V : 176°
Audio amplifier
3W g 2 5W g 2 5W g 2
Speaker
(128.8 mm g 40.2 mm) g 2 (164.5 mm g 42 mm) g 2 (164.5 mm g 42 mm) g 2
Rear
Antenna
UHF/VHF 75 q
RS-232C 3 pin connector (For service only)
SCART 1 SCART (AV input, Y/C input, RGB input, TV output )
SCART 2
(Only for 26” and 32”)
SCART (AV input, Y/C input, monitor output [analogue source - ATV, SCART 1, SIDE AV;
digital source - DTV] )
PC IN D-sub 15 pin (AV input), Ø 3.5mm jack (Audio input)
Component Y/Pb(Cb)/Pr(Cr), RCA pin (L/R)
SPDIF Digital audio output
AUDIO OUT RCA pin (L/R)
AV OUT (Only for 19”) RCA pin (AV output)
HDMI 1
HDMI 2 (Only for 26” and 32”)
Side
C. I. (Common Interface) EN50221, R206001
Headphones Ø 3.5mm jack (Audio output)
AV IN RCA pin (AV input).
S-VIDEO ( [Y/C input], Only for 26” and 32”)
HDMI 3 (Only for 32”)
OSD language English, German, French, Italian, Dutch, Spanish, Greek, Portuguese, Swedish, Finnish,
Russian, Polish, Turkish, Hungarian, Czech, Slovak, Danish, Norwegian, Estonian, Latvian,
Lithuanian, Slovenian, Bulgarian, Croatian, Romanian, Serbian, Ukrainian, Gaelic.
Power Requirement AC 220–240 V, 50 Hz
Power Consumption 45W (Standby < 0.3W)
(Method IEC62087)
55W (Standby < 0.3W)
(Method IEC62087)
135W (Standby < 0.3W)
(Method IEC62087)
Weight 3.8 kg (Without stand),
4.0 kg (With stand)
7.3 kg (Without stand),
8.4 kg (With stand)
11.0kg (Without stand),
12.4 kg (With stand)
Operating temperature
0°C to k40°C
Specification
24

Sharp LC-26SH7E Specifications

General

Comb filter	Digital
Display diagonal	26 \
Display brightness	450 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	150 °
Contrast ratio (dynamic)	8000:1
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Power requirements	220 - 240V AC, 50 - 60Hz
Headphone connectivity	3.5 mm
SCART ports quantity	2
Digital audio coaxial out	1
Product color	Black
Panel mounting interface	200 x 100 mm
Power consumption (standby)	0.3 W
Power consumption (typical)	55 W
RMS rated power	10 W
Tuner type	Analog & digital

Weight and Dimensions

Depth (with stand)	239.8 mm
Width (with stand)	657.8 mm
Height (with stand)	491.1 mm
Weight (with stand)	8400 g
Depth (without stand)	91.6 mm
Height (without stand)	448.4 mm
