PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32/40/46/52LE700UN
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] DUNTKF282FM01/02 (MAIN Unit)
[4] DUNTKE266FM02 (KEY Unit)
[5] DUNTKF308FM01 (R/C, LED Unit)
[6] DUNTKF314FM01 (ICON Unit)
[7] CABINET PARTS (LC-32LE700UN)
[8] LCD PANEL MODULE
(LC-32LE700UN)
[9] CABINET PARTS (LC-40LE700UN)
[10] LCD PANEL MODULE
(LC-40LE700UN)
[11] CABINET PARTS (LC-46LE700UN)
[12] LCD PANEL MODULE
(LC-46LE700UN)
[13] CABINET PARTS (LC-52LE700UN)
[14] LCD PANEL MODULE
(LC-52LE700UN)
[15] SUPPLIED ACCESSORIES
[16] PACKING PARTS
(LC-32/40LE700UN)
(NOT REPLACEMENT ITEM)
[17] PACKING PARTS
(LC-46/52LE700UN)
(NOT REPLACEMENT ITEM)
[18] SERVICE JIGS
(USE FOR SERVICING)
CONTENTS
No. S79B2LC32L70U
LCD COLOR TELEVISION
LC-32LE700UN
LC-40LE700UN
LC-46LE700UN
LC-52LE700UN
MODELS
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
