Sharp LC-39LE650E Service Manual

121
LC-39/50LE650
LC-39/50LE651
LC-39/50LE652
PARTS
DELIVERY SECTION (G: EPC SHARP GmbH)
REF No. PARTS
DESCRIPTION
*
PRICE
CODE
RLCDTA283WJZZ LCD 39" 100Hz FHD V390HK1-LE6 CMI
P
--
RLCDTA282WJZZ MODULE LCD 50" 100Hz FHD V500HK1-LE6 CMI
P
--
DUNTKG135FM04 MAIN PWB / ADJUST MAIN UNIT LE750/LE650
P
--
DUNTKG135FM07 MAIN PWB / ADJUST MAIN UNIT LE752 /LE652
P
--
DUNTKG135FM08 MAIN PWB / ADJUST MAIN UNIT LE751/LE651
P
--
DUNTKG221WE01 TOUCH KEY +R/C+3D IR PWB/KEY UNIT
P
--
¡ RDENCA459WJQZ POWER UNIT W/O LED DRIVER 39"/50" CMI
P
--
RKEYEA006WJZZ CI+ KEY SERIES LE65x / LE75x ST MICRO
P
--
IC 0503 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 0540 VHINC7SZ04P-1Y IC INVERTER GATE NC7SZ04P5X (FAIRCHILD)
IC 0552 RH-IXD540WJZZY IC VIDEO AMPLIFIER +6dB BH76206HFV(ROHM)
LE650
IC 1102 RH-IXD519WJZZY IC Si2165-D-GMR SiLABS, DVB-T/C DEMOD
LE651
IC 1103 RH-IXD525WJZZQ IC Si2168-A30-GM SiLABS, DVB-T/C/T2 DEMO
IC 1104 VHIS132B50M-1Y IC S-1132B50-M5T1G LDO 5V (SEIKO)
IC 1106 RH-IXD518WJZZY IC Si2178-A20-GMR SiLABS, SILICON TUNER
IC 1505 VHIBU16028V-1Q IC 3TO1 HDMI SWITCH BU16028KV-ZAE (ROHM)
IC 1506 VHITC7SH08U-1Y IC 2-INPUT AND GATE TC7SH08-FU (TOSHIBA)
IC 1507 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1508 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1509 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1510 VHIBR24T02J-1Y IC NVM 2Kb BR24T02J (ROHM)
IC 1511 VHIESD7004M-1Y Suppresor HDMI Array, ESD7004MUTAG (ON S
IC 1512 VHIESD7004M-1Y Suppresor HDMI Array, ESD7004MUTAG (ON S
IC 2701 VHISTA333BW-1L IC 40W AUDO AMPL. 2.1 STA333BM(ST MICRO)
IC 2702 RH-IXD542WJZZY IC TS488IQT POPFree HeadPhones Ampl (ST
IC 3301 RH-IXD514WJZZQ IC FLI7560-AAB CUT1.1 STMICRO FREEMAN PR
IC 3302 VHIS80927NM-1Y CI S-80927CNMC-G8XT2G
IC 3303 VHIBR24T64J-1Y IC NVM 64Kb BR24T64FJ-WE2 (ROHM)
IC 3501 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3502 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3503 RH-IXD538WJZZQ ICDDR3-1600 MT41J128M16JT-125:K(MICRON)
IC 3800 RH-IXD550WJZZY IC CPU STM8S105K4T6CTR (ST MICRO)
IC 4401 VHILCX245FT-1Y CI TC74LCX245FT(EL,K)
MARK * : SPARE
LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
LE650 / LE651 MAIN Unit
DUNTKG135WE04 / 08
INTEGRATED CIRCUITS
LC-39/50LE650E
LC-39/50LE651K
LC-39/50LE652E
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identied in this manual.
Electrical components having such features are identied by in the Replacement Parts
Listing.
The use of a substitute replacement part which does not have the same safety characteristics
as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock re, or other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
REF No. PARTS
DESCRIPTION
*
PRICE
CODE
IC 4402 VHILCX244FT-1Y CI TC74LCX244FT(EL,K)
IC 4403 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG
IC 4404 VHILCX244FT-1Y CI TC74LCX244FT(EL,K)
IC 8401 RH-IXD551WJQZQ IC NANDFLASH 2Gb MT29F2G08ABAEAWP:E(MICR
IC 9501 RH-IXD543WJZZY IC ETH-PHY RMII, KSZ8081RNDCATR (MICREL)
IC 9551 RH-IXD187WJZZY CI AAT4614IGU-2-T1 ANALOGIC TECH
IC 9552 VHI2514BAEZ-1Q IC USB2514B-AEZG
IC 9553 VHIS170B50U-1Y CI S-1170B50UC-0UJTFG
IC 9601 VHIBD9328EF-1Y IC BD9328EFJ 2A DCDC ROHM
IC 9602 RH-IXD534WJZZY IC BD95841MUV-E2 (Rohm)
IC 9603 VHIS170B25U-1Y IC S-1170B25UC LDO 2.5V (SEIKO)
IC 9605 VHIS132B50M-1Y IC S-1132B50-M5T1G LDO 5V (SEIKO)
IC 9606 RH-IXD533WJZZY IC BD80GA3WEFJ LDO (Rohm)
IC 9608 RH-IXD532WJZZY IC BU33TD3WG LDO (Rohm)
IC 9701 VHIBD9328EF-1Y IC BD9328EFJ 2A DCDC ROHM
Q 1101 VSMMBT2907A-1Y TRT MMBT2907ALT1G
Q 1501 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI
Q 1502 VSRT1N441U/-1Y TRT RT1N441U-T111-1
Q 1505 VS2N7002KA+-1Y TRT 2N7002KA-RTK/P (KEC)
Q 2602 VS2SC3928AR-1Y TRT 2SC3928AR-T112-1R MITSUBISHI
Q 2604 RH-TXA064WJZZY TRT AO3415 P-Channel Mosfet ALPHA & OMEG
D 0501 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0502 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0503 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0504 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0511 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0529 VHDDAN202K/-1Y DIODO DAN202KT146
D 0540 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0556 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0559 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0560 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0561 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 0562 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1102 VHEVBUS05L1-1Y ESD DIODE VBUS05L1-DD1-G-08 VISHAY
D 1501 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1502 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1503 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1504 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1505 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1506 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1507 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1508 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1509 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1511 RH-EXA741WJQZY ZENER DIODE 5.6V DZ2J056MOL(PANASONIC)
D 1513 VHDDAN202K/-1Y DIODO DAN202KT146
D 1514 VHDDAN202K/-1Y DIODO DAN202KT146
D 1515 VHDDAN202K/-1Y DIODO DAN202KT146
D 1516 VHDDAN202K/-1Y DIODO DAN202KT146
D 2707 VHDHSU119//-1Y DIODO HSU119TRF
D 2708 VHDHSU119//-1Y DIODO HSU119TRF
D 3301 VHDRB520S30-1Y DIODO RB520S-30
D 3805 VHDHSU119//-1Y DIODO HSU119TRF
DIODES
TRANSISTORS
