3. Remote control key operation in Service Mode (Adjustment process mode).
The required input mode should be switched previously to enter the Service Mode.
CAUTION: Use due care in handling the information described here lest the users should know how to enter the
adjustment process mode. If the settings are tampered with in this mode, unrecoverable system
damage may result.
4. Description of display
In gure 1 the selected Menu is remarked by CYAN color, but same criteria is valid on internal SubMenus.
Please use the remote keys as is explained in “3. Remote control key operation in Service Mode” to access to all the options
described below.
Remote Control key Keyboard unit Function
Cursor (◄/►) Moving an item by one (LEFT/RIGHT) on “Service Menu”.
Moving an item by one (LEFT/RIGHT) on SubMenus.
Moving a Slider Horizontal Bar to select a value on SubMenu Function.
Cursor (▼/▲ ) Enter on a SubMenu (▼).
Exit from a SubMenu (▲).
Exit of Service Mode (Adjustment mode).
OK Selecting a MENU on “Service Menu”
Selecting a SubMenu.
Executing a function on a SubMenu.
MENU MENU Exit of Service Mode (Adjustment mode).
Return to “Service Menu” from a SubMenu.
0..9
Enter numeric data on SubMenu Function.
i ( k / l) VOL
( k / l)
Volume UP or DOWN.
P (r / s)
CH
(r / s)
Channel UP or DOWN (Only in ATV/DTV mode), otherwise no action.
b
INPUT
No action
System
Data
GUI
Exception
Chassis
Options
Station
list
DVB
EPG
Service
Figure 1: Main Service Adjustment Menu
