LC-42/46/52D64U
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R9741 VRS-CZ1JF473JY AA J Resistor, 47k 1/16W Metal Oxide
SC1601 QSOCZA072WJZZQ AH J Socket, 23pin (TMDS Input 1)
SC1602 QSOCZA072WJZZQ AH J Socket, 23pin (TMDS Input 2)
SC1603 QCNCWA661WJQZY AG J Connector, 21pin (HM)
SC2201 QSOCNA707WJZZ AF X Socket, 17pin
SC2203 QCNCWA673WJZZY AF J Connector, 80pin (MA)
SC9001 QSOCNA706WJZZ AE X Socket, 11pin
SC9201 QCNCWA715WJQZY AK N X Connector, 10pin
SC9202 QCNCWA715WJQZY AK N X Connector, 10pin
SG1601 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1602 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1603 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1604 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1607 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1608 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1609 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1610 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1613 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1614 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1615 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1616 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1619 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1620 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1621 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG1622 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
TH2001 VHHM1103J03-1Y AC J Thermistor
X1401 RCRSCA145WJZZY AE J Crystal, 12.288MHz
X1501 RCRSCA146WJZZY AE J Crystal, 28.322MHz
X2002 RFILZA023WJQZY AD J Filter
X3201 RCRSC0191TAZZY AE J Crystal
X8001 RCRSCA167WJQZY AG J Crystal, 54.000MHz
[4] DUNTKE208FM01 (TERMINAL Unit)
C501 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C503 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C510 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C512 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C513 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C514 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C515 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C516 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C517 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C518 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C519 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C524 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C526 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C528 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C530 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C534 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C535 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C537 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C539 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C540 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C541 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C543 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C544 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C545 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C546 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C547 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C548 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C549 VCERMZ1CN107MY AD J Capacitor, 100 16V Electrolytic
C550 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C551 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C552 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C553 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C554 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C555 VCKYTV1CB105KY AC J
Capacitor, 1 16V Ceramic
C557 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C559 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C560 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C561 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C562 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C563 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C564 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C565 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C566 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C567 RC-KZA154WJZZY AB J Capacitor, 4.7 16V Ceramic
C568 RC-KZA154WJZZY AB J Capacitor, 4.7 16V Ceramic
C569 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C570 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C571 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C572 RC-KZA237WJZZY AB J Capacitor, 10 16V Ceramic
C573 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C574 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C575 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
[3] DUNTKE207FM01 (MAIN Unit)
