Sharp LC-42D64U User Manual

LC-42/46/52D64U
5 – 6
6 [HDTV]
1 COMP33K ADJ (INPUT1) Component 33K picture level adjustment (main)
2 COMP33K ADJ (INPUT3)
3 COMP33K Y A_GAIN
4 COMP33K Cb A_GAIN
5 COMP33K Cr A_GAIN
6 COMP33K Y OFFSET Y OFFSET adjustment value
7 COMP33K Cb OFFSET Cb OFFSET adjustment value
8 COMP33K Cr OFFSET Cr OFFSET adjustment value
7 [ANALOG RGB]
1 ANALOG RGB ADJ Analog RGB picture level adjustment
2R CUTOFF
3 G CUTOFF
4 B CUTOFF
5 R DRIVE
6 G DRIVE
7 B DRIVE
8 [M GAMMA IN]
1 LEV1 Standard value 1 Adjustment gradation setting.
2 LEV2 Standard value 2
3 LEV3 Standard value 3
4 LEV4 Standard value 4
5 LEV5 Standard value 5
6 LEV6 Standard value 6
9 [M GAMMA R1]
1 MG1R WB adjustment Point 1, R adjustment value Parameter for six-point adjustment
2 MG1G WB adjustment Point 1, G adjustment value
3 MG1B WB adjustment Point 1, B adjustment value
4 MG2R WB adjustment Point 2, R adjustment value
5 MG2G WB adjustment Point 2, G adjustment value
6 MG2B WB adjustment Point 2, B adjustment value
7 MG3R WB adjustment Point 3, R adjustment value
8 MG3G WB adjustment Point 3, G adjustment value
9 MG3B WB adjustment Point 3, B adjustment value
10 [M GAMMA R4]
1 MG4R WB adjustment Point 4, R adjustment value Parameter for six-point adjustment
2 MG4G WB adjustment Point 4, G adjustment value
3 MG4B WB adjustment Point 4, B adjustment value
4 MG5R WB adjustment Point 5, R adjustment value
5 MG5G WB adjustment Point 5, G adjustment value
6 MG5B WB adjustment Point 5, B adjustment value
7 MG6R WB adjustment Point 6, R adjustment value
8 MG6G WB adjustment Point 6, G adjustment value
9 MG6B WB adjustment Point 6, B adjustment value
11 [SOUND 1]
1 Audio Switch
2 Flat Mode
3 ADC Volume 1
4 ADC Volume 2
5 ADC Volume 3
6 ADC Volume 4
7 ADC Volume 5
8 ADC Volume 6
9 LR Fanc Vol AIN
10 LR Fanc Vol HDMI
11 LR Fanc Vol ATV
12 LR Fanc Vol DTV
13 Input Trim
Page Line Item Description Remarks (adjustment detail, etc.)

Sharp LC-42D64U Specifications

General

Brand	Sharp
Model	LC-42D64U
Category	TV
Language	English
