Sharp LC-60LE650U User Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
iv
LC-60LE650U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF953FM06) in case of IC3103 and IC3104 failure.
*2 Replace LCD CONTROL Units (DUNTKF975FM20) in case of IC5803 failure.(LC-60/70LE650U/C6500U/LE657U)
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref NO. PARTS CODE DESCRIPTION
LC-60/70LE650U/C6500U/LE657U
N DKEYMF953FM06 MAIN Unit
N DUNTKF975FM20 LCD CONTROL Unit
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit (LC-60/70LE657U)
N DUNTKG014FM03 ICON Unit (LC-60/70LE650U/C6500U)
N DUNTKG015FM03 R/C OPC Unit
N RUNTKA936WJQZ Wi-Fi Unit
N RUNTKB126WJQZ BLUETOOTH Unit (LC-60/70LE657U)
N RUNTKB109WJQZ POWER/LED DRIVER Unit (LC-60LE650U/C6500U/LE657U)
N RUNTKB131WJQZ POWER/LED DRIVER Unit (LC-70LE650U/C6500U/LE657U)
LC-60/70LE755U/757U/857U/C7500U
N DKEYMF953FM06 MAIN Unit
N DUNTKF961FM19 LCD CONTROL UNIT (LC-60LE755U/757U/857U/C7500U)
N DUNTKF961FM20 LCD CONTROL UNIT (LC-70LE755U/757U/857U/C7500U)
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit (LC-60/70LE755U/757U/857U)
N DUNTKG014FM03 ICON Unit (LC-60/70C7500U)
N DUNTKG015FM03 R/C OPC Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60LE755U/757U/857U/C7500U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70LE755U/757U/857U/C7500U)
N RUNTKA936WJQZ WiFi Unit
N RUNTKB126WJQZ BLUETOOTH Unit (LC-60/70LE755U/757U/857U)
Ref NO. PARTS CODE DESCRIPTION
N R1JE600D3GV2AZ 60" LCD PANEL MODULE Unit (JE600D3GV2AZ) (LC-60LE650U/C6500U/LE657U)
N R1JE695D3GW8CD 70" LCD PANEL MODULE Unit (JE695D3GW8CD) (LC-70LE650U/C6500U/LE657U)
N R1JE600D3HD60Z 60" LCD PANEL HIRAKI (Open Cell) Unit (LC-60LE755U/757U/857U)
N R1JE695D3HB10Z 70" LCD PANEL HIRAKI (Open Cell) Unit (LC-70LE755U/757U/857U)
Ref No. Parts No. Description Q’ty
IC2004 RH-iXD515WJN7Q IC (Monitor Microprocessor) 1
Ref No. PARTS CODE DESCRIPTION Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2 2
N QCNW-L214WJQZ
Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2 (LC-60/70LE755U/
757U/857U)
2
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW) 1
N QCNW-M539WJQZ Connecting Cord L=1000mm 24-24/4pins, Power-Main/LCD Control (PD) 1

Sharp LC-60LE650U Specifications

General

Display diagonal	60 \
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	4000000:1
Viewing angle, horizontal	176 °
3D	No
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
HDMI version	1.4
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	Aquos Link
Electronic Program Guide (EPG)	-
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Power consumption (typical)	188 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	360 mm
Height (with stand)	851 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	826 mm
Weight (without stand)	25000 g
