Sharp R-15AM Service Manual

30
R-15AM
∆
∆
∆
∆
∆
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
∆
*
*
*
ELECTRIC PARTS
AM RMOTDA234WRE0 Antenna motor 1 AR
C RC-QZA320WRZZ High voltage capacitor 1 AV
F1 QFS-CA026WRZZ Fuse F10A 1 AH
F2 QFS-IA002WRE0 High voltage fuse 1 AQ
FM RMOTEA378WRE0 Fan motor 1 AU
MG RV-MZA299WRE0 Magnetron 1 BK
OL RLMPTA078WRE0 Oven lamp 1 AL
OL RLMPTA069WRE0 Oven lamp (Interchangeable) 1 AK
R RR-WZA022WRE0 Monitor resistor 0.8 ohm 20 W 2 AK
SW1 QSW-MA085WRE0 1st. interlock switch 1 AF
SW2 QSW-MA085WRE0 2nd. interlock relay control switch 1 AF
SW3 QSW-MA086WRE0 Monitor switch 1 AF
T RTRN-A717WRZZ High voltage transformer 1 BP
TC1 RTHM-A123WRZZ Thermal cut-out 125 deg. (OVEN) 1 AK
TC1 RTHM-A096WRE0 Thermal cut-out 125 deg. (OVEN) (Interchangeable) 1 AK
TC2 RTHM-A120WRE0 Thermal cut-out 145 deg. (MAG) 1 AH
TC2 RTHM-A080WRE0 Thermal cut-out 145 deg. (MAG) (Interchangeable) 1 AP
1- 1 QACC-A148WRZZ Power supply cord 1 AW
1- 2 FH-DZA091WRK0 High voltage rectifier assembly 1 AY
1- 3 QSOCLA024WRE0 Oven lamp socket 1 AH
1- 4 FPWBFA367WRKZ Noise filter 1 AZ
CABINET PARTS
2- 1 GCABUA672WRP0 Outer case cabinet 1 BH
2- 2 GDAI-A318WRW0 Base plate 1 AV
2- 3 GCOVHA406WRW0 Base plate cover 1 AQ
2- 4 GLEGPA074WRE0 Foot 2 AC
2- 5 GLEGPA076WRF0 Leg 1 AF
CONTROL PANEL PARTS
3- 1 DPWBFC157WRKZ Control unit 1 BM
3- 2 FPNLCB772WRKZ Control panel frame assembly 1 BA
3- 2-1 GCOVAA330WRRZ C/P case 1 BA
3- 3 JBTN-B263WRTZ Select button 1
3- 4 JKNBKA657WRTZ Timer knob 1 AQ
3- 5 XEPSD30P08XS0 Screw; 3mm x 8mm 7 AA
OVEN PARTS
4- 1 FGLSPA062WRE0 Ceramic shelf 1 BL
4- 2 DOVN-A514WRY0 Oven cavity 1 BU
4- 3 MLEVPA227WRF0 Latch switch lever A 1 AF
4- 4 MLEVPA228WRF0 Latch switch lever B 1 AF
4- 5 MLEVPA229WRF0 Latch switch lever C 1 AF
4- 6 MSPRCA108WRE0 Latch lever spring 3 AC
4- 7 MSPRTA191WRE0 Switch lever B spring 1 AC
4- 8 PHOK-A121WRFZ Latch hook 1 AG
4- 9 FDUC-A362WRYZ Steam duct sub assembly 1 BB
4-10 PSKR-A351WRP0 Steam guide 1 AY
4-11 LBNDKA139WRW0 HV capacitor holder 1 AR
4-12 NFANJA029WRE0 Fan blade 1 AK
4-13 PDUC-A697WRF0 Fan duct 1 AM
4-14 FPLT-A007WRY0 Stirrer antenna assembly 1 BB
4-15 PCUSUA507WRP0 Cushion 1 AC
4-16 PCUSGA378WRP0 Cushion 1 AL
4-17 PSPA-A112WRE0 Mica washer 1 AC
4-18 LANGFA199WRWZ Chassis support 1 AH
4-19 NSFTPA035WRFZ Antenna motor shaft 1 AQ
4-20 PSKR-A359WRW0 Air guide 1 AM
4-21 PSKR-A349WRP0 Steam duct barrier 1 AF
4-22 PFILWA060WRP0 Lamp filter 1 AD
4-23 PDUC-A722WRF0 Air intake duct 1 AF
4-24 PCUSGA249WRP0 Cushion 1 AA
4-25 PCUSUA235WRP0 Cushion 1 AE
4-26 PCUSUA511WRP0 Cushion 2 AC
4-27 PCUSUA329WRP0 Cushion 1 AC
4-28 PCUSUA514WRP0 Cushion 1 AB
4-29 PPACGA171WRE0 Cushion 1 AK
4-30 PCUSUA515WRP0 Cushion 1 AD
4-31 PSHEPA668WRE0 Cover 1 AK
4-32 PCLICA034WRE0 Hand clip 3 AD
4-33 PSHEPA673WRE0 S/Film 1 AD
4-34 GLEGPA056WRE0 Leg 1 AD
