Sharp R-610DKA User Manual

33
R-610DKA
R-610DWA
R-610DSA
*
*
*
*
*
*
*
∆
*
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 FACCDA085WREZ Power supply cord 1 AQ
1- 1 FACCDA083WRE0 Power supply cord (Interchangeable) 1 AQ
1- 2 QFSHDA009WRE0 Fuse holder 1 AH
1- 3 QSW-MA137WRE0 2nd interlock switch / door sensing switch 2 AH
1- 3 QSW-MA085WRE0 2nd interlock switch / door sensing switch(Interchangeable) 2AF
1- 4 FFS-BA023WRK0
Monitor fuse 20A and monitor switch (AM51620C53Y1) assembly 1AS
1- 5 RTHM-A116WRE0 Thermal cut-out 125 deg. C (MG) 1 AK
1- 5 RTHM-A078WRE0 Thermal cut-out 125 deg. C (MG) (Interchangeable) 1 AK
1- 6 FH-DZA101WRKZ High voltage rectifier assembly 1 AT
1- 6 FH-DZA097WRKZ High voltage rectifier assembly (Interchangeable) 1 AP
1- 7 RC-QZA286WRZZ High voltage capacitor 1 AV
1- 7 RC-QZA268WRZZ High voltage capacitor (Interchangeable) 1 AS
1- 7 RC-QZA211WRE0 High voltage capacitor (Interchangeable) 1 AV
1- 8 RMOTEA401WRZZ Fan motor 1 AX
1- 8 RMOTEA395WRZZ Fan motor (Interchangeable) 1 AW
1- 9 RTRN-A636WRZZ Power transformer 1 BL
1- 9 RTRN-A609WRZZ Power transformer (Interchangeable) 1 BK
1-10 RV-MZA310WRZZ Magnetron 1 BG
1-11 RLMPTA082WRZZ Oven lamp 1 AL
1-12 RMOTDA186WRE0 Turntable motor 1 AW
1-12 RMOTDA229WRE0 Turntable motor (Interchangeable) 1 AQ
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A123WRZZ Thermal cut-out 125 deg. C (OVEN) 1 AK
1-13 RTHM-A096WRE0 Thermal cut-out 125 deg. C (OVEN) (Interchangeable) 1 AK
CABINET PARTS
2- 1 FDAI-A240WRYZ Base plate 1 AW
2- 2 GLEGPA074WRE0 Foot 1 AC
2- 3 GLEGPA081WRFZ Leg 1 AC
2- 4 GCABUA773WRPZ Outer case cabinet [R-610DKA] 1 BD
2- 4 GCABUA775WRPZ Outer case cabinet [R-610DWA] 1 BD
2- 4 GCABUA777WRPZ Outer case cabinet [R-610DSA] 1 BD
2- 5 GLEGPA080WRFZ Front leg [R-610DKA] 1 AL
2- 5 GLEGPA082WRFZ Front leg [R-610DWA] 1 AL
2- 5 GLEGPA080WRFZ Front leg [R-610DSA] 1 AL
2- 6 PPACGA180WREZ Cushion 1 AC
POWER UNIT PARTS
3- 1 DPWBFC174WRUZ Power unit 1 BE
3- 1A QCNCMA431DRE0 2-pin connector (CN-B) 1 AC
3- 1B QCNCMA469DRZZ 7-pin connector (CN-C) 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31EW108M Capacitor 1000 uF 25V 1 AE
C21 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
D1-4 RH-DZA006PRE0 Diode (1N4002) 4 AD
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D40 VHD1SS270A/-1 Diode (1SS270A) 1 AA
Q21 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q22 VSDTA143ES/1B Transistor (DTA143ES) 1 AA
R4 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
RY2 RRLY-A114DRE0 Relay (DU12D1-1P(M)-R) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA110DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
OVEN PARTS
4- 1 PHOK-A118WRFZ Latch hook 1 AH
4- 2 LBNDKA099WRW0 Capacitor holder 1 AD
4- 3 LFLG-A028WREZ Bearing 1 AL
4- 4 FANGKA211WRWZ Fan case assembly 1 AP
4- 5 LANGRA055WRWZ Fan motor mounting angle 1 AE
4- 6 LANGRA056WRWZ Bearing holder 1 AF
4- 7 NFANJA046WREZ Closs flow fan 1 AG
4- 8 LANG-A069WRPZ Magnetron air guide A 1 AL
4- 9 LANG-A080WRWZ Magnetron air guide B 1 AC
4-10 PPACGA084WRF0 TTM packing 1 AE
