REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-11 LANG-A081WRWZ Separate angle B 1 AD
4-12 ************* Oven cavity (Not a replaceable part) 1--
4-13 GCOVHA419WRFZ Choke cover 1 AK
4-14 LANGQA536WRWZ Lamp angle 1 AS
4-15 LANG-A077WRPZ Magnetron thermal cut-out angle 1 AC
4-16 PCOVPA361WREZ Waveguide cover 1 AD
4-17 PCUSGA057WRP0 Cushion 1 AA
4-18 PCUSUA557WRPZ Cushion 1 AC
4-19 PCUSUA556WRPZ Cushion 1 AC
4-20 PCUSUA126WRE0 Cushion 1 AC
4-21 PPACGA177WREZ Cushion 1 AC
4-22 PCUSGA505WRP0 Cushion 1 AB
4-23 PCUSUA376WRP0 Cushion 1 AF
4-24 PCUSUA409WRP0 Cushion 1 AD
4-25 PCUSUA558WRPZ Cushion 1 AC
4-26 PDUC-A751WRTZ Exhaust duct 1 AP
4-27 LANGFA200WRPZ Support angle 1 AD
4-28 PCUSUA375WRP0 Cushion 1 AH
4-29 PCUSUA562WRPZ Cushion 1 AB
4-30 PCUSUA568WRPZ Cushion 1 AE
DOOR PARTS
5- 1 FDORFA343WRTZ Door panel 1 AS
5- 2 PSHEPA735WREZ Sealer film 1 AG
5-3-1 FUNTKB082WREZ Key unit [R-610DKA] 1 AT
5-3-1 FUNTKB083WREZ Key unit [R-610DWA] 1 AT
5-3-1 FUNTKB082WREZ Key unit [R-610DSA] 1 AT
5-3-2 HPNL-A768WRRZ Door screen [R-610DKA] 1 AZ
5-3-2 HPNL-A770WRRZ Door screen [R-610DWA] 1 AZ
5-3-2 HPNL-A768WRRZ Door screen [R-610DSA] 1 AZ
5- 3 FWAKPA338WRKZ Door frame assembly [R-610DKA] 1 BF
5- 3 FWAKPA340WRKZ Door frame assembly [R-610DWA] 1 BF
5- 3 FWAKPA342WRKZ Door frame assembly [R-610DSA] 1 BF
5- 4 JHNDPA203WRTZ Handle [R-610DKA] 1 AP
5- 4 JHNDPA203WRTZ Handle [R-610DWA] 1 AP
5- 4 JHNDPA205WRTZ Handle [R-610DSA] 1 AQ
5- 5 LANGKA975WRPZ Handle mounting angle 1 AP
5- 6 LSTPPA193WRFZ Latch head 1 AE
5- 7 MSPRTA187WRE0 Latch spring 1 AC
5- 8 LHLD-A242WRFZ LCD holder 1 AE
5- 9 LHLD-A237WRFZ Light guide 1 AL
5-10 PSHEPA786WREZ LED sheet 1 BB
5-11 FW-VZA271DREZ 7-pin wire harness 1 AQ
5-12 DPWBFC212WRKZ CPU unit 1 BC
5-13 PCOVPA367WRWZ PWB cover 1 AD
5-14 PCUSUA569WRPZ Cushion 1 AE
5-15 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
5-16 XEPSD40P16000 Screw : 4mm x 16mm 2 AA
5-17 XEPSD30P08XS0 Screw : 3mm x 8mm 3 AA
5-18 XEPSD40P08000 Screw : 4mm x 8mm 7 AA
MISCELLANEOUS
6- 1 FROLPA097WRKZ Turntable support 1 AN
6- 2 NTNT-A099WRE0 Turntable tray 1 AX
6- 3 FW-VZB850WREZ Main wire harness 1 AW
6- 4 QW-QZA242WRZZ High voltage wire B 1 AF
6- 5 FW-VZB802WREZ T.T. motor harness 1 AF
6- 6 TCAUAA156WRR0 User caution label 1 AF
6- 7 TCAUAA201WRR0 DHHS caution label 1 AE
6- 8 TCAUAA254WRR0 Monitor caution label 1 AC
6- 9 TCAUAA255WRR0 Screw caution 1 AC
6-10 TINSEA911WRRZ Instruction book 1 AD
6-11 FW-VZB801WREZ Switch harness 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 4 AA
7- 2 XBPSD40P08K00 Screw : 4mm x 8mm 2 AA
7- 3 XOTSD40P08000 Screw : 4mm x 8mm 12 AA
7- 4 XHTSD40P06000 Screw : 4mm x 6mm 2 AA
7- 5 XCPSD40P08000 Screw : 4mm x 8mm 1 AA
7- 6 XHPSD30P08XS0 Screw : 3mm x 8mm 2 AB
7- 7 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
∆
