Sharp R-950A Service Manual

R-950A
2
PRODUCT SPECIFICATIONS
ITEM DESCRIPTION
Power Requirements 220 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption 1600 W (Microwave) 3150 W (Microwave + Convection)
1600 W (Convection) 2600 W (Microwave + Grill )
1050 W (Grill, 2600 W initially)
Power Output 900 watts (IEC-705)
Operating frequency of 2450MHz
Convection heater 1500 W
Grill heater 1000 W
Case Dimensions Width 627mm
Height 378mm
Depth 492mm
Cooking Cavity Dimensions Width 410mm
Height 245mm
Depth 410mm
Control Complement Touch Control System
Clock ( 1:00 - 12:59)
Timer (0 - 99 min. 99 sec.)
Microwave Power for Variable Cooking
Repetition Rate;
HIGH.............................................. Full power throughout the cooking time
MED HIGH........................................................ approx. 70% of Full Power
MED................................................................... approx. 50% of Full Power
MED LOW (DEFROST) ..................................... approx. 30% of Full Power
LOW .................................................................. approx. 10% of Full Power
CONVECTION COOKING FUNCTION Temperature for Variable Cooking
CONVECTION ................................................... 40 to 250˚C Temp. control
SIMUL CONVECTION .......................230˚C with 30% of microwave power
GRILL COOKING FUNCTION
GRILL ...................................................................................... Grill cooking
SIMUL GRILL ..........................Grill cooking with 30% of microwave power
HELP pad
AUTO REHEAT pad AUTO COOK pad
AUTO ROAST pad AUTO GRILL pad
AUTO BAKE pad MORE. LESS pads
POWER LEVEL pad EASY DEFROST pad
KITCHEN TIMER pad
NUMBER and TEMPERATURE pads
STOP/CLEAR pad CLOCK pad
INSTANT COOK/START pad
Set Weight Approx. 29 kg
GENERAL INFORMATION
WARNING
THIS APPLIANCE MUST BE EARTHED
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE

Sharp R-950A Specifications

Power

ac line voltage	220 V
microwave frequency	2450 MHz
ac power required (microwave)	1.6 kW
ac power required (convection)	1.6 kW
ac power required (grill)	1.05 kW
ac power required (simul)	3.15 kW

Oven Specifications

oven capacity	41 litre
output power (microwave)	900 W
output power (convection heater)	1500 W
output power (grill heater)	1000 W

Weight and Dimensions

width	627 mm
height	378 mm
depth	492 mm
cavity width	410 mm
cavity height	245 mm
cavity depth	410 mm
weight	29 kg
