23
T242 Trimmer
B
A
C
D
E
D
IMPORTANT!
When the wear indicators (D) located at the bottom of the
Speed-Feed® trimmer head are worn smooth, or if holes
appear, replacement of the trimmer head cover (E) or the
entire Speed-Feed® head is required.
Nylon Line Replacement
CAUTION!
Wear gloves or personal injury may result:
■ Cutoff knife is sharp.
■ Gearcase and surrounding area may be hot.
1. Cut one piece of nylon line to recommended length.
.080 (2.0 mm) dia. – 20' (6 m)
.095 (2.4 mm) dia. – 20' (6 m)
2. Align arrows on top of knob (A) with openings in
eyelets (B).
Trimmer head is now fully loaded and ready
for operation.
3. Insert one end of nylon line into an eyelet, and push
line equal distance through trimmer head.
4. Hold trimmer head while turning knob (C)
clockwise to wind nylon line onto spool until
about 5" (13 cm) of each line remains exposed.
