Shure Incorporated
24/27
Specifications
Inputs
ANI4IN-XLR (4) XLR connector
ANI4IN-BLOCK (4) 6-pin block connector
Phantom Power
selectable per channel
+48 V
Logic Connections (Block connectors only)
Sent as Ethernet command strings
LED(+5 V), Switch
Polarity
Non-inverting, any input to any output
Output
(1) RJ45
Power Requirements
Power over Ethernet (PoE), Class 0
Power Consumption
10W, maximum
Weight
672 g (1.5 lbs)
Dimensions
H x W x D
4 x 14 x 12.8 cm (1.6 x 5.5 x 5.0 in.)
control application
HTML5 Browser-based
Operating Temperature Range
−6.7°C (20°F) to 40°C (104°F)
