Shure LX1 Service Manual

Shure LX4 Diversity Receiver
Replacement Parts and Drawings2325D1008 (BK)
Replacement Parts and Drawings
Parts Designations
The following comments apply to the parts list and the schematic:
Resistors: All resistors are surface-mount with
1
/
10
W rating and 1%
tolerance.
Capacitors: Unless otherwise noted, non-polarized capacitors are
surface-mount
NPO dielectric types with a 100 V capacity and a 5%
tolerance, and polarized capacitors are tantalum types.
Table 3
Replacement Parts
Reference
Designation
Description
Shure Part Number
A1 *Printed circuit board assembly T90__8632 [See Table 2, p. 14 to
determine the frequency-code in the
underlined space. e.g.T90CA
8632].
E1 Whip antenna 90A8380 for 169–186MHz
90B8380 for 186–204MHz
90C8380 for 204–240MHz
MP1 Cable, connector assy, DC jack 90B8688
MP2 Hex Nut .8mm (power connec-
tor)
95Z8562
MP3 Washer (power connector) 95Y8562
MP4 Front, lens assembly 90A8633
MP5 Knob, volume 65B8249A
MP6 Knob, power 65A8250
MP7 Hardware Kit 90TZ1371
MP8 Mounting bracket 53A8350
MP9 Mounting bracket 53A8381
MP10 Bracket, rf connector 53A8367
MP11 Heat sink, regulator 80A8187
Y1* Crystal 40_8003A [See Table 2, p. 14 to
determine the crystal code in the
underlined space. e.g. 40NY
8003A].
