English
13
Attaching the LX1 to a Belt or Guitar Strap (Figure 12)
Attach the LX1 body-pack transmitter clip to a belt, waistband, or guitar strap by de-
pressing the tab marked PRESS and slipping the belt or strap between the transmitter
body and the belt clip, as shown in Figure 11. The clip holds tightest if the material is
drawn to the clip’s top wire (especially thinner guitar straps).
BELT OR GUITAR STRAP
ATTACHING THE LX1 TO A BELT OR GUITAR STRAP
FIGURE 12
Installing the WA555 Grip/Switch Cover Accessory
on the LX2 (Figure 13)
The LX2 transmitter comes with an external sleeve accessory (WA555) that pre-
vents accidental movement of the microphone controls without affecting RF perfor-
mance. It also provides the microphone with a “grip” feel. To install the grip/switch cov-
er, proceed as follows:
WA555 GRIP/SWITCH
COVER
INSTALLING THE OPTIONAL LX2 GRIP/SWITCH COVER ACCESSORY
FIGURE 13
ÑÑ
1
2
3
1. Unscrew the battery cover.
2. Slide the cover over the microphone handle, “lip” end downward. The cover fits
snugly and requires additional pressure for the last inch of travel.
3. Reinstall the battery cover.
