Shure LX1 User Manual

Wireless
20
Net Weight
LX1: 79 g (2.8 oz.) without battery
LX2/58, LX2/BETA 58: 295 g (10.4 oz.) without battery
LX2/87, LX2/BETA 87: 193 g (6.8 oz.) without battery
LX3: 1,049 g (2 lbs, 5 oz.)
LX4: 1,105 g (2 lbs, 7 oz.)
CERTIFICATION
LX1,LX2 Transmitters: Type Accepted under FCC Parts 74 and 90. Certified by IC in Can-
ada under TRC-78.
LX3, LX4 Receivers: Approved under the Notification provision of FCC Part 15. Certified
by IC in Canada under TRC-78.
LX1, LX2, LX3, LX4: RA Type Approved to MPT 1345, MPT 1350, ETS 300 422. BZT Type
Approved to FTZ 17TR 2019, BAPT 122 R1.
Meets Requirements of EMC Standard EN 301 489 Parts 1 and 9. Meets Low Voltage
Directive. LX Systems are eligible to carry the CE marking.
Shure Models LX1 and LX2 Transmitters meet the essential requirements of the
European R&TTE Directive 99/5/EC and are eligible to carry the CE marking.
O682
Shure Models LX3 and LX4 Receivers meet the essential requirements of the European
R&TTE Directive 99/5/EC and are eligible to carry the CE marking.
Power supply meets the following safety standard:
PS40 Power Supply: UL 1310, CAN/CSA 22.2 No. 223.
PS40E Power Supply: EN 60950
PS40UK Power Supply: EN 60950
FURNISHED ACCESSORIES
Microphone Stand Adapter (LX2) WA370A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Single Receiver HR Rack Panel Kit WA500. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dual Receiver (Side–by–Side) HR Rack Panel Kit (LX4) WA502. . . . . . . . . . . . . . . . . . .
Grip/Switch Cover (LX2) WA555. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Zipper Bag (LX1) 26A13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Zipper Bag (LX2) 26A13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screwdriver 80A498. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPTIONAL ACCESSORIES
Instrument Adapter Cable, 1/4” Plug (LX1) WA302. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Adapter Cable, Right-Angle 1/4” Plug (LX1) WA304. . . . . . . . . . . . . . . . . . . .
Microphone Adapter Cable (LX1) WA310. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-Pin Female Mini-ConnectorTA4F (LX1) WA330. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In-Line Audio Switch (LX1) WA360. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Telescoping Antenna (169 - 185 MHz) WA380A*. . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Telescoping Antenna (185 - 200 MHz) WA380B*. . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Telescoping Antenna (200 - 230 MHz) WA380C*. . . . . . . . . . . . . . . . . . . . . . . .
Antenna/Power Distribution System, 120 Vac WA405. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna/Power Distribution System, 230 Vac WA405E. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.8 Meter (6 ft.) Receiver-Mixer Cable (
1
/
4
” phone to XLR) WA410. . . . . . . . . . . . . . . . .
6.1 Meter (20 ft.) Antenna Extension Cable WA421. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna Rack Mount Kit WA440. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passive Antenna Splitter WA470. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Cable Antenna (169 - 185 MHz) WA490A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Cable Antenna (185 - 200 MHz) WA490B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
/
2
-Wave Cable Antenna (200 - 216 MHz) WA490C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Single Receiver Front-Mount Antenna Conversion Kit WA503. . . . . . . . . . . . . . . . . . . . .
Pelican Protector

Carrying Case for Single LX or SC Wireless System WA525. . . . .
Nylon Carrying Case WA590. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
∗Includes wall-mount bracket.
