OPERATING LX1 BODY–PACK SYSTEMS (FIGURE 14)
1. Clip the LX1 body pack transmitter to your belt, waistband, or guitar strap.
2. Connect the lavalier microphone, headset or instrument adapter cable to the body–
pack transmitter.
3. If you are using a lavalier microphone, clip the mic to your tie, lapel, or other gar-
ment. If you are using a headset, put the headset on. If you are using a Shure WM98
microphone, insert it into an A98KCS horn mount and clamp it to your horn. If you
are using an instrument adapter cable, plug the cable into the instrument.
4. Slide the transmitter PWR/OFF switch to the PWR position. One of the three lights
on the transmitter illuminates.
5. Press the POWER button on the receiver. The green “power on” light on the receiver
and the RF light(s) illuminates.
6. Slide the transmitter ON/MUTE switch to the ON position and begin speaking or
playing your instrument.
NOTE: If the red PEAK light on the receiver does not flicker during the loudest sounds,
the transmitter gain may need to be increased. Refer to the Adjusting the Transmitter
Audio Gain Level section. Then, if the system is still not operating properly, consult the
Troubleshooting table.
7. During the performance or presentation, slide the ON/MUTE switch to the MUTE
position when the system is not in use.
8. When the performance or presentation is over, slide the transmitter PWR/OFF
switch to the OFF position to conserve battery power.
