3 Supported hardware
3.1 2D LiDAR sensors
LiDAR-LOC is qualified for the SICK sensor family microScan3.
NOTICE
SIC
K does not guarantee that the system functions with other sensors.
Table 1: Supported sensor data
Supported sensor
d
ata
2D LiDAR sensor
Supported device (pro‐
tective field range)
microScan3
4.0 m
microScan3
5.5 m
microScan3
9.0 m
Aperture angle 275°
Distance range 1.8 %: 4 m
100 %: 40 m
1.8 %: 5.5 m
100 %: 40 m
1.8 %: 9 m
100 %: 64 m
Scan cycle time 30 ms
40 ms
40 ms
50 ms
For additional information, consult the operation instructions of the corresponding sen‐
sor
.
For high quality of the localization, we recommend to consider the following information
about the sensors.
microScan3
•
Protective field range 9 m (64 m warning field range)
The sensors with 64 m measurement range are preferred over the ones with 40 m
me
asurement range. They can be used in both configurations, 50 ms and 40 ms
scan cycle time. Smaller scan cycle times allow potentially higher velocities, how‐
ever, are primarily dependent on your risk assessment.
•
Pr
otective field range 4 m and 5.5 m (40 m warning field range)
When using the sensors with 40 m measurement range, they can be used in both
conf
igurations, 40 ms and 30 ms scan cycle time, with corresponding 0.39° and
0.51° resolution. A smaller scan cycle time allows potentially higher velocities. A
higher resolution allows the detection of smaller objects. However, the configura‐
tion is primarily dependent on your risk assessment.
Complementary information
Y
ou can find additional information of the microScan3 in the operating instructions:
•
8020198 microScan3 EtherNet/IP
TM
•
8021217 microScan3 PROFINET
•
8021911 microScan3 EFI-pro
3.2 Localization controllers
Localization controllers
L
iDAR-LOC uses the SIM1000-FXA. For quick integration, some information is provided
in this document.
3 SUP
PORTED HARDWARE
6
T E C H N I C A L I N F O R M A T I O N | LiDAR Localization Hardware Integration 8024819/2019-09-02 | SICK
Subject to change without notice
