Operating Instructions
LMS1xx Laser Measurement Sensors
Product description
8012471/ZN27/2017-06-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 19
Chapter 3
3.3 Type code
3.3.1 Marking scheme of LMS variants (without special devices)
LMS a b c - dd e 00
Not all possible combinations are available according to the type code.
3.3.2 Marking scheme of LMC variants (without special devices)
LMC a b c - dd e ff
Not all possible combinations are available according to the type code.
Placeholder Characteristics Variant
a Device family 1: LMS1xx
b Variant 0: Indoor housing without heating, IP 65
1: Outdoor housing with heating, IP 67
2: Security indoor housing without heating, IP 65
3: Security outdoor housing with heating, IP 67
4: Security outdoor housing with heating, IP 67,
scanning range max. 40 m
5: Outdoor housing with heating, IP 67,
scanning range max. 50 m
7: Security indoor housing without heating, IP 65, special device
8: Security outdoor housing with heating, IP 67, special device
c Housing color 0: blue
1: gray
2: black
3: white
dd Performance 05: Core, with extended ambient temperature range
–40 °C ... + 60 °C
10: Standard/Prime
11: VdS certifed
15: Standard /Prime, with extended ambient temperature range
–40 °C ... + 60 °C
e Connectivity 0: System connector/PG
1: M12 Standard
Tab. 7: Type code of LMS1xx
Placeholder Characteristics Variant
a Device family 1: LMC1xx
b Variant 2: Security indoor housing without heating, IP 65
3: Security outdoor housing with heating, IP 67
c Housing color 1: gray
2: black
3: white
4: black (sensor) / installation set uncoated
dd Performance 11: VdS certifed
e Connectivity 0: System connector/PG
1: M12 Standard
ff Mounting types 00: installation set VdS 1
01: installation set VdS 2
Tab. 8: Type code of LMC1xx
