Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Smart Infrastructure Connection diagrams and dimensions 2019-04-09
SA..81.. SAS81.33, SAS81.33U
A Actuator
F1 Temperature limiter
N1 Controller
SN System neutral
SP System potential AC/DC 24 V
Y1, Y2 Positioning signals
SAS81.0..
SA..81..
