Word Logic Instructions with the Contents of Accumulator 1
33
S7-400 Instruction List
A5E00267845-01
Word Logic Instructions with the Contents of Accumulator 1
Gating the contents of ACCU1 and/or ACCU1-L with a word or double word according to the appropriate function. The word or double word
is either specified in the instruction as an address or is in ACCU2. The result is in ACCU1 and/or ACCU1-L.
In-
Length
Execution Time in s
tion
ID
CPU 412 CPU 414 CPU 416 CPU 417
AW AND ACCU2-L 1 0.1 0.06 0.04 0.03
AW W#16#p AND 16-bit constant 2 0.125 0.075 0.05 0.042
OW OR ACCU2-L 1 0.1 0.06 0.04 0.03
OW W#16#p OR 16-bit constant 2 0.125 0.075 0.05 0.042
XOW EXCLUSIVE OR ACCU2-L 1 0.1 0.06 0.04 0.03
XOW W#16#p EXKLUSIV-ODER EXCLUSIVE
OR 16-bit constant
2 0.125 0.075 0.05 0.042
Status word for: UW, OW, XOW BR CC1 CC0 OV OS OR STA RLO /FC
Instruction evaluates: – – – – – – – – –
Instruction affects: – ja 0 0 – – – – –
