Introduction
1.2Description
Universal Power Supply Options
• Fully integrated, dual-redundant (optional) power supplies
• Universal high-voltage range: 88-300 VDC or 85-264 VAC
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950-1 safety approved to 85 °C (185 °F)
1.2 Description
The RUGGEDCOM RSG2100 features various ports, controls and indicator LEDs on the
display panel for connecting, configuring and troubleshooting the device. The dis-
play panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
3
4
2
1
5
7
6
1
Fiber or Copper Ethernet Ports
2
Port Status Indicator LEDs
3
Mode Button
4
RS-232 Serial Console Port (RJ45)
5
Display Mode Indicator LEDs
6
Alarm Indicator LED
7
Power Module Indicator LEDs
Figure1.1 RUGGEDCOM RSG2100
Communication Ports Ports for communicating with other devices or accessing the
RUGGEDCOM RUGGEDCOM RSG2100 operating system are de-
scribed in "Communication Ports (Page 23)".
Port Status Indicator LEDs Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
Mode Color/State Description
Green (Solid) Link detected
Green (Blinking) Link activity
Status
Off No link detected
Green Full duplex mode
Orange Half duplex mode
Duplex
Off No link detected
Speed Green (Solid) 100 Mbps
2
RUGGEDCOM RSG2100
Installation Manual, 03/2020, C79000-G8976-1040-17
