Siemens RUGGEDCOM RX1510 User Manual

Installing the Device
2.5.2Connecting Low DC Power
Figure2.9 DC Terminal Block Wiring – Screw Terminal Block for 12P, 24P and 48P Power
Supplies
4
1
3
2
1
Not Connected
2
European-style (Euroblock) Terminal Block
3
Positive (+) Terminal
4
Negative (-) Terminal
5
Ground Terminal
Figure2.10 DC Terminal Block Wiring – European-style (Euroblock) Terminal Block for
-12P, -24P and -48P Power Supplies
5
2
3
4
5
6
1
4
1
6
1
Not Connected
2
Removable Screw Terminal Block
3
Non-removable Screw Terminal Block
4
Positive (+) Terminal
5
Negative (-) Terminal
RUGGEDCOM RX1510
Installation Manual, 12/2019, C79000-G8976-1055-16
15
