8.4 SCALANCE XB004-2LD
Hardware version
You will 󹪝nd the hardware version of your device on the type plate. On the type plate, the
hardware version is printed as a placeholder “X”.
Example: X 2 3 4 5 6
In this case, "X" would be the placeholder for hardware version 1.
Table 8-4 Technical speci󹪝cations of the SCALANCE XB004-2LD
Technical speci󹪝cations
Article number
SCALANCE XB004-2LD 6GK5 004-2BF00-1AB2
Connection to Industrial Ethernet
Quantity 4
Design RJ-45 jacks with MDI‑X pinning
Properties Half / full duplex
Transmission rate 10/100 Mbps
Optical connectors
Quantity 2
Design SC sockets
Properties Full duplex acc. to 100Base-LX
Transmission rate 100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type Single mode glass FO cable
Cable cross-section 9/125 μm
Permitted cable length 0 to 26,000 m
Attenuation ≤ 0.5 dB/km at 1310 nm
14 dB max. permitted FO cable attenuation with
2 dB link power margin
Electrical data
Power supply Rated voltage 24 V DC
Voltage range 19.2 to 28.8 V DC Safe Extra Low Voltage
(SELV)
Design 3-terminal plug-in block
Technical speci󹪝cations
8.4 SCALANCE XB004-2LD
SCALANCE XB-000
64 Operating Instructions, 01/2022, A2B00077300-11
