1)
as of hardware version 5
Note
The number of IE switches of the SCALANCE XB-000 product line connected in a line inuences
the frame delay.
When a frame passes through IE switches of the SCALANCE XB‑000 product line, it is delayed by
the store and forward function of the switch
• with a 64 byte frame length by approx. 10 microseconds (at 100 Mbps)
• with a 1500 byte frame length by approx. 130 microseconds (at 100 Mbps)
This means the more devices of the SCALANCE XB‑000 product line that the frame passes
through, the longer the frame propagation time.
Hardware version
You will nd the hardware version of your device on the type plate. On the type plate, the
hardware version is printed as a placeholder “X”.
Example: X 2 3 4 5 6
In this case, "X" would be the placeholder for hardware version 1.
8.6 SCALANCE XB008
Note
Note the article number in the technical specications.
Table 8-6 Technical specications of the SCALANCE XB008 (6GK5 008-0BA00-1AB2)
Technical specications
Article number
SCALANCE XB008 6GK5 008-0BA00-1AB2
Attachment to Industrial Ethernet
Quantity 8
Design RJ-45 jacks with MDI‑X pinning
Properties Half / full duplex
Transmission rate 10/100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via IE FC RJ45 Outlet
Technical specications
8.6 SCALANCE XB008
SCALANCE XB-000
68 Operating Instructions, 01/2022, A2B00077300-11
