Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Technical data for the SED2 01.2002
200 V to 240 V, ± 10%, 3 phases
Output power
(variable torque)
IP code
Filter
class
Max.
input current
3 phases
Max.
output
current
Frame size
Type
(ASN)
kW hp IP A A
30 40 20 unfiltered 114 104 E SED2-30/22X
37 50
20 unfiltered 143 130 F SED2-37/22X
45 60 20 unfiltered 170 154 F SED2-45/22X
380 V to 480 V, ± 10%, 3 phases
Output power
(variable torque)
IP code
Filter
class
Max.
input current
3 phases
Max.
output
current
Frame size
Type
(ASN)
kW hp IP A A
0.37 0.5 20 B 1.6 1.2 A SED2-0.37/32B
0.55 0.75 20 B 2.1 1.6 A SED2-0.55/32B
0.75 1
20 B 2.8 2.1 A SED2-0.75/32B
1.1 1.5 20 B 4.2 3 A SED2-1.1/32B
1.5 2 20 B 5.8 4 A SED2-1.5/32B
2.2 3
20 B 7.5 5.9 B SED2-2.2/32B
3 4 20 B 10 7.7 B SED2-3/32B
4 5 20 B 12.8 10.2 B SED2-4/32B
5.5 7.5
20 B 16.6 13.2 C SED2-5.5/32B
7.5 10 20 B 24 18.4 C SED2-7.5/32B
11 15 20 B 33.8 26 C SED2-11/32B
15 20
20 B 42 32 C SED2-15/32B
18.5 25 20 B 45.7 38 D SED2-18.5/32B
22 30 20 B 50 45 D SED2-22/32B
30 40
20 B 68 62 D SED2-30/32B
37 50 20 B 83 75 E SED2-37/32B
45 60 20 B 99 90 E SED2-45/32B
55 75 20 B 121 110 F SED2-55/32B
75 100 20 B 160 145 F SED2-75/32B
90 125 20 B 196 178 F SED2-90/32B
0.37 0.5 20 unfiltered 1.6 1.2 A SED2-0.37/32X
0.55 0.75
20 unfiltered 2.1 1.6 A SED2-0.55/32X
0.75 1 20 unfiltered 2.8 2.1 A SED2-0.75/32X
1.1 1.5 20 unfiltered 4.2 3 A SED2-1.1/32X
1.5 2
20 unfiltered 5.8 4 A SED2-1.5/32X
2.2 3 20 unfiltered 7.5 5.9 B SED2-2.2/32X
3 4 20 unfiltered 10 7.7 B SED2-3/32X
45
20 unfiltered 12.8 10.2 B SED2-4/32X
5.5 7.5 20 unfiltered 16.6 13.2 C SED2-5.5/32X
7.5 10 20 unfiltered 24 18.4 C SED2-7.5/32X
11 15
20 unfiltered 33.8 26 C SED2-11/32X
15 20 20 unfiltered 42 32 C SED2-15/32X
18.5 25 20 unfiltered 45.7 38 D SED2-18.5/32X
22 30
20 unfiltered 50 45 D SED2-22/32X
