Siemens SED2 Series User Manual

115/126
Siemens Building Technologies SED2 variable speed drives CM1U5192en
HVAC Products Technical data for the SED2 01.2002
IP54 / NEMA 12
Framesize WxHxD(mm)
Weight (kg)
with filter without filter
B 270 x 385 x 268 11.5 10.3
C 360 x 606 x 284 21 19.2
D 360 x 685 x 353 35 35
E 360 x 885 x 453 48 48
F 450 x 1150 x 428 99 81
8.2 Type-specific data
200 V to 240 V, ± 10%, 3 phases
Output power
(variable torque)
IP code
Filter
class
Max.
input current
3 phases
Max.
output
current
Frame size
Type
(ASN)
kW hp IP A A
0.37 0.5 20 B 2.4 2.3 A SED2-0.37/22B
0.55 0.75 20 B 3.1 3 A SED2-0.55/22B
0.75 1
20 B 4.3 3.9 A SED2-0.75/22B
1.1 1.5 20 B 6.2 5.5 B SED2-1.1/22B
1.5 2 20 B 8.3 7.4 B SED2-1.5/22B
2.2 3
20 B 11.3 10.4 B SED2-2.2/22B
3 4 20 B 15.6 13.6 C SED2-3/22B
4 5 20 B 20.1 17.5 C SED2-4/22B
5.5 7.5
20 B 26.3 22 C SED2-5.5/22B
7.5 10 20 B 36.4 28 C SED2-7.5/22B
11 15 20 B 46 42 D SED2-11/22B
15 20
20 B 60 54 D SED2-15/22B
18.5 25 20 B 75 68 D SED2-18.5/22B
22 30 20 B 88 80 E SED2-22/22B
30 40
20 B 114 104 E SED2-30/22B
37 50 20 B 143 130 F SED2-37/22B
45 60 20 B 170 154 F SED2-45/22B
0.37 0.5 20 unfiltered 2.4 2.3 A SED2-0.37/22X
0.55 0.75
20 unfiltered 3.1 3 A SED2-0.55/22X
0.75 1 20 unfiltered 4.3 3.9 A SED2-0.75/22X
1.1 1.5 20 unfiltered 6.2 5.5 B SED2-1.1/22X
1.5 2
20 unfiltered 8.3 7.4 B SED2-1.5/22X
2.2 3 20 unfiltered 11.3 10.4 B SED2-2.2/22X
3 4 20 unfiltered 15.6 13.6 C SED2-3/22X
45
20 unfiltered 20.1 17.5 C SED2-4/22X
5.5 7.5 20 unfiltered 26.3 22 C SED2-5.5/22X
7.5 10 20 unfiltered 36.4 28 C SED2-7.5/22X
11 15
20 unfiltered 46 42 D SED2-11/22X
15 20 20 unfiltered 60 54 D SED2-15/22X
18.5 25 20 unfiltered 75 68 D SED2-18.5/22X
22 30
20 unfiltered 88 80 E SED2-22/22X
Dimensions and weight
(frame sizes B to F
IP54 / NEMA 12)
