C7-Ein-/Ausgabebaugruppe / C7 Input Output Module
15
Produktinformation
/ Product Information
C79000-Z7074-C630-01
Prinzipschaltbild
Digitaleingänge
24 V
1L+
M
intern
1M
Prinzipschaltbild Digitalausgänge
2L+
2M
Bild 1-6 Prinzipschaltbilder der Digitalein–/ ausgänge
