Dimension drawings
9.2 Extender dimension drawings
SCALANCE XM-400
76 Operating Instructions, 09/2018, C79000-G8976-C306-08
9.2
Extender dimension drawings
Note
Installing on a rail
Remember the following dimensions if you want to mount two devices on a rail.
Front view
